Power: Manual
Media: Gas, Oil, Water
Brand Name: Yongda
Structure: Globe
Pressure: Medium Pressure
Standard or Nonstandard: Standard
Material: Casting
Temperature of Media: Medium Temperature
Port: Shanghai
Payment Terms: L/C, T/T
Delivery Time: Delivery depends on quantity
Globe valve features:
1) Size: 1/2" - 36", DN15-DN900
2) Class: 150 - 1500lbs, or PN16 - PN250
3) Material: WCB, LCB, LCC, LC3, WC1, WC6, WC9, C5, C12, CF8, CF8M, CF3,
CF3M, etc.
4) Design &Manufacture Standards: BS1873, ANSI B16.34
5) Face to face: ANSI B16.10, DIN 3202, BS2080
6) End flange: Up to 24 ANSI B16.5 from 26 MSS SP44 ANSI B16.47
BW( Butt-weld) end: ANSI B16.25
7) Connection End: ASME B16.5, ASME B16.11, DIN2543-2551
8)Test: API598
9) Operator: Handwheel, gear, electric actuator, Pneumatic, hydraulic.
Features:
A. Outside Screw &Yoke
B. Bolted Bonnet
C. Screw Seat Ring up to 6
D. Welded Seat Ring from 8
E. Available with Gear Operator
F. Special features according to Customers requirement
(cast steel globe valve, stainless steel globe valve)
Our company was founded in 1987, located in Zhangjiagang, Jiangsu Province. We have built up long-term cooperation with our customer all over the world, such as the US, the Netherlands, and Italy. We have extensive experience on producing various types of valves. Our quality products wins a high degree of evaluation.
Our products include ball valves, gate valves, check valves, cut-off valves, and reed valves. Our products are widely used in petroleum projects, chemical industry, and sewage treatment. Our specifications are 4 saves-24 inches (reed valve may make 48 inches). We can also supply OEM service.
The company enhance the mettle of "expoition and innovation, better and better" and promise of "quality first, customers first". As a manufacture, tech research, sales and service combined company, we honestly provide you service of valves. Any question about valves can you find answer from our experts, and also, we sincerely hope a long term cooperation with you.
