Above offer including following:
*high pressure pump
*Pressure regulating valve
*Safety Valve
*Pressure gauge
*Hose
* Oil Cooler system
*Gear Pump
* Spare parts (free)
*Tools with Machine
Technical data:
Pressure: 700Bar
Flow:70Lpm
Motor speed: 1480 RPM
Speed of Pump: 332RPM
Stroke: 100mm
Plunger Dia: 30mm
Gear Ratio: 4.45
Power:90Kw
| Plunger Diameter mm | Flow (L/M) | Power (Kw) |
| 75 | 90 | 110 |
| Pressure (Bar) |
| P16 | 20 | 1700 | | |
| P18 | 25 | 1500 | | |
| P20 | 30 | 1300 | 1500 | |
| P22 | 37 | 1000 | 1300 | 1500 |
| P24 | 45 | 850 | 1000 | 1250 |
| P26 | 52 | 750 | 900 | 1050 |
| P28 | 60 | 650 | 800 | 950 |
Boss was set up in 2009 in Wuxi, it takes 1 hour from Shanghai Railway station to our factory.
Business scope: Vavle and pump develope, manufacture, sell and service.
Looking for abroad companies agent biz
Advantage:
1, CNC machines 20 sets
2, production lines: 4
3, CE, asme products
4, follow Germany and Italy technology
5, 3 stores and 2 factoreis
Company Policy: Honest, Service, Quality
Welcome to your visit warmly.
