Carbon steel ball valves thread ball valve ansi standard ball valves
1, Features:
1. Blow-out Proof Stem
2. Investment Casting Body
3. Pressure Balance Hole in Ball Slot
4. Full Port
5. Anti-Static Device upon request
6. Various Thread Standard Available
7. Locking Device Available
2, Carbon steel ball valves thread ball valve ansi standard ball valves
1). Size: 1/4", 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2", 2-1/2", 3"
2). Material: WCB, 304, 316 (CF8, CF8M)
3). Pressure: 1000PSI, 1000WOG
4). Suitable medium: Water, oil, air and some corrosive liquid
5). Temperature range: -20° C-232° C
6). Design and manufacture: ASME B16.34
7). Wall Thickness: 100% ASME B16.34
8). Face to face: DIN 3202-M3
9). Pipe Thread: ANSI B 1.20.1, BS 21/2779, DIN 259/2999, ISO 228-1
10). Inspection & Testing: API 598
11). Threaded end: NPT, BSPT, BSP, DIN259/2999 Full Bore
12). Operation: Manual
13). Locking device (option)
14). ISO-5211 mounting pad for actuator (option)
15). Certificate: API, CE, TS, ISO, AZ
3, CASTING AND VALVE MANUFACTURE FLOW DIAGRAM
Suitable medium
|
Water, oil, air and some corrosive liquid
|
MOQ
|
1 Piece
|
Packing
|
Plastic bag, carton, plywood cases
|
Term of delivery
|
FOB, CIF, CNF, Customer request available
|
Port
|
NINGBO, SHANGHAI, Customer request available
|
Delivery time
|
15-40 days after confirm order
|
|
EVK FITTING GROUP Co., Ltd (China) is a leading group, engaged in manufacturing valve, pipe fitting and flange, affilicating Qingdao EVK Industrial Co., Ltd, Yantai EVK Valve Manufacturing Co., Ltd, Hebei EVK Pipe Fitting Co., Ltd and Tianjin EVK Flange Fabrication Co., Ltd. EVK Group has more than 2000 staffs and covers around 150000 square meters totally.
Main production includes:
Valve: Cast iron/Ductile iron/Cast steel/Forged steel Valve( DIN3352 Resilient seated F4/F5 Gate valve, DIN3352 F4/F5 metal seated Gate valve, BS5163/BS5150/AWWA C509 Gate valve, API600 Gate valve, Wafer/Lug/Double flange butterfly valve, DIN/MSS Globe valve, Wafer/swing check valve, Y-strainer, JIS marine valve)
Pipe fitting: Carbon steel butt welding pipe fitting(Elbow, Straight and reducing tee, concentric and eccentric reducer, cap), Forged steel pipe fitting(Elbow, Tee, Reducer), Malleable iron pipe fitting.
Flange: Carbon steel and stainless steel forged flange(Flat flange, welding neck flange, slip on flange, blind flange).
Autoparts: Brake shoes, Brake pads, Brake discs, Brake drums.
We exported to more than 25 countries in the world, our main customers have CRANE, WALWORTH, OARI, etc. Our company was awarded with ISO9001 certificate and CE for our valve, pipe fitting and flange products.
Our blief is "Do friend first, Do business second", we welcome all friends from all over the world to do business together!
