| Price: | US $ 90/Piece |
|---|---|
| Trade Terms: | FOB,EXW |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T |
High Quality High Temperature Ball Valve Applicable standards
Design STD: API 6D, ISO14313, API 608
Steel ball valves ISO 14313
Fire durable API 607, ISO10497
Anti static API 608
Face to face ASME B16.10-2000(R2003) API 6D-2002
End connection: ASME B16.5
Buttwelding ends ASME B16.25
Inspection and test API6D,ISO5208,API598
Design description
Size 2"-30"
ANSI Class 150~1500Lb
Working temperature: -46 ~550
Medium: water, oil, acid medium, etc.
Top entry ball valve
Full port design
One piece body
Bolted bonnet, split body
Three piece body for 12" and above
Trunnion mounted ball type
Blow-out proof stem
Fire durable construction
Anti static device
Stopper device
Lifting lugs & supporting feet ( 8" & above)
ISO 5211 mounting pad
Flanged or buttwelding ends connection
Available with worm gear, handwheel, motor,
pneumatic actuator
Except High Quality High Temperature Ball Valve,we can also offer customer other ball valve,gate valve,globe valve,check valve, butterfly valve,safety valve and so on. If you have any demand,pls kindly send us the inquiry. We'll try our best to support you.
Packing:
|
Product name: |
High Quality High Temperature Ball Valve |
|
Size: |
2"-36" |
|
Pressure: |
Class 150LB – 600 LB |
|
Connection: |
RF/RTJ Flange, Butt Weld |
|
Material: |
A182, F304, F316,A105, A216, WCB , WCC ,LCC , LCB |
|
Operating Type: |
Lever, worm Gear actuator,Electric actuator, Pneumatic actuator |
|
Design and Manufacture: |
API, DIN, JIS, GB... |
| Prod Model: | Top entry ball valve |
|---|---|
| Markets: | North America,South America,Eastern Europe,Oceania,Western Europe |
| Size: | 2"-36" |
| Drive Mode: | Manual, Electric, Hydraulic, Worm Gear |
| Certification: | CE, API6a, 6D, 600, GOST, ISO9001, Ta-Luft, Az |
| Design Standard: | GB, Jb, API, DIN, Bs, JIS |
| Connection Form: | Flange |
| Channel: | Straight Through Type |
| Structure: | Fixed Ball Valve |
| Type: | Fixed Ball Valve |
| Application: | Water Industrial Usage |
| Material: | Cast Steel |
