Pneumatic conveying system
1. Suitable for conveying powder, granular, and block materials (temperature <200° C)
2. Level and incline transportation, reliable, durable, adaptable
3. Not only used for the concrete batching plant, bituminous concrete batching, but also for the chemical, building, food, metallurgy and so on.
Introduction of pneumatic conveying system
Pneumatic conveying system is the updated model of the GX type screw conveyor. The whole conveyor is reliable, durable, adaptable, easy to install. It is suitable for conveying the powder, granular, and block materials (temperature <200º C), such as coal powder, coal ash, argil, sand, cement, carbamide etc. The screw conveyor is not only used for the concrete batching plant, bituminous concrete batching, but also for the chemical, building, food, metallurgy and so on.
Working principle of pneumatic conveying system
Pneumatic conveying system consists of a shaft with a spiral blade and chute. The Shaft is installed at both ends of chute bearing base through bearing. The shaft head on one side of shaft connected with driving device. There are feeding inlet and discharging outlet on the top and bottom of chute.
Materials get into conveyor through feeding inlet. Subject to the reverse thrust of screw blade, the materials can rotate with shaft as for radial force of thrust and friction between blade and material. As a result of material itself gravity and friction between chute and materials, the materials do not rotate with spiral blade but move along the chute on the effect of axial thrust of blade radial thrust force. Materials move forward in spiral form, that is moving forward accompanied with tumbling motion in circumferential direction.
Features of pneumatic conveying system
1. Compared with GX type screw conveyor, Cement/Concrete Screw Conveyor eliminates the possibility of reducing bearing life because of untight seal and material leakage, as heading and rear bearings are removed outside the frame.
2. Simple structure, small floor space, low noise, good sealing, easy operation and maintenance.
3. High applicability, convenient feeding inlet and discharging outlet, easy for multi-point feeding and discharge materials.
Company Brief Introduction
SHANGHAI CLIRIK MACHINERY CO., LTD located in PUDONG New district of Shanghai china, as a pioneer enterprise, which is specializing in research, manufacture and sales of all kinds of grinding mill, all kinds of crushers from coarse grinding mill, fine grinding mill and ultra fine grinding mill, grinding mill related equipment, such as powder modifying machine, powder packing machine. Powder conveying system, etc. We have devoted into grinding field for more than 30 years, we belive only focus can be professional.
Our company has already formed a full set of modern production line, equipped with intelligent, standardized testing and controlling laboratories, owned a professional team for R&D, production, sales and service.
Inquiry Service of pneumatic conveying system
Please fill in your need products and your message and please do not forget mail and/or phone if you like to be contacted. We are the professional machine manufacturer in China with 30 years experience. Pls kindly check the following, in order to select a suitable machine, send you specific techinical data, quotation and the solution drawing for you.
1. What is the raw material do you want to convey?
2. What is the capacity per hour do you need?
3. What is the raw material input size?
4. What is the conveying length you need?
We hope you can tell us these details, we will give you the best quotation, technical data and solution drawing ASAP, thanks. Your satisfaction is our greatest pursuit, we would like to sincerely for your service! We look forward to your inquiry!
| Model | ST-LXB-0.5 | ST-LXB-2 | ST-LXB-5 | ST-LXB-10 | ST-LXB-15 | ST-LXB-20 | ST-LXB-30 | ST-LXB-40 | ST-LXB-50 |
| Capacity(t/h) | 0.1 ~ 0.5 | 0.5 ~ 2 | 2 ~ 5 | 5 ~ 10 | 10 ~ 15 | 15 ~ 20 | 20 ~ 30 | 30 ~ 40 | 40 ~ 50 |
Blast Capacity
(m³/min) | 1.0 ~ 3.0 | 8.0 ~ 12 | 10 ~ 15 | 12 ~ 18 | 14 ~ 23 | 18 ~ 30 | 20 ~ 38 | 35 ~ 50 | 40 ~ 65 |
| Inlet Pipe Diameter | DN40/
DN50 | DN100/
DN125 | DN125/
DN150 | DN125/
DN150 | DN125/
DN150 | DN150/
DN175 | DN150/
DN200 | DN200/
DN250 | DN200/
DN300 |
| Velocity in Pipe (m/s) | 13 ~ 16 |
| Pressure (kpa) | ≤78 |
| Body Material | Cast Iron, Cast Steel, Stainless |
| Motor(kw) | 0.5 | 1.5 | 2.2 | 2.2 | 2.2 | 3.0 | 3.0 | 3.0 | 4.0 |
| Weight (kg) | 650 | 770 | 960 | 1100 | 1100 | 1200 | 1300 | 1450 | 1600 |
