Y-Ball Valve
Y-Ball Valve— Product Introduction
One valve control two pipes
Y-Ball Valve— Pressure
≤ 0.7MPa
Y-Ball Valve— Product Improvement
Automatic control, one ball valve can automatically open and close the valve
This design has obtained national patent in May 2011, patent number: ZL201020575061.8.
Y-Ball Valve— Advantages
Y-Ball Valve
Xinhai wear - resistant rubber as the liners of Y- ball valve with 128% wear resistance index
Service lige is 2-4 times longer than traditional valve.
The ball wrapped by Xinhai wear - resistant rubber which can effectively open and close the two valve ports in Y - ball valve.
Slurry flow driving ball into a pipe orifice and close it; Slurry pass by another pipe orifice. So it will not cause blockage.
The Y- ball valve relying on the pressure of slurry to change the valve does not need people to control realizing automatic control, simple and flexible. Adopting Y- ball valve realizes pipeline setting of two pumps with one valve.
Y-Ball Valve— Product Description
Outstanding ball valve design of opening and closing, no blocking; Creative opening and closing device control the valve by slurry pushing the ball
Y-Ball Valve
Y- Ball valve realizes pipeline setting of two pumps with one valve to reduce the investment cost by only buying one valve and saving one pipeline.
Y-Ball Valve— Application
Y-Ball Valve
Xinhai Y-Ball valve is mainly used for pulp, slags, tailings, drainage system of spare pump and chemical corrosive substance delivery.
Specification (DN) |
A |
B |
C |
Flange Dimension |
Center distance of bolt holes |
Outside diameter of flange |
n-Φd |
65 |
247 |
227 |
197 |
145 |
185 |
4-Φ18 |
80 |
267 |
250.5 |
217 |
160 |
200 |
8-Φ18 |
100 |
308.5 |
296 |
256.5 |
180 |
220 |
8-Φ18 |
125 |
352 |
346 |
300 |
210 |
250 |
8-Φ18 |
150 |
410 |
400 |
346.5 |
240 |
285 |
8-Φ22 |
200 |
477 |
476.5 |
413 |
295 |
340 |
8-Φ22 |
250 |
569 |
569 |
493 |
350 |
395 |
12-Φ22 |
300 |
656 |
669.5 |
580 |
400 |
445 |
12-Φ22 |
350 |
735 |
761 |
659 |
460 |
505 |
16-Φ22 |
400 |
833.5 |
863 |
747.5 |
515 |
565 |
12-Φ26 |
450 |
922.5 |
952 |
824.5 |
565 |
615 |
20-Φ26 |
500 |
1011 |
1054 |
913 |
620 |
670 |
20- Φ26 |
Performance Standard
Nominal Pressure |
0.7Mpa |
Test Pressure(Mpa) |
Sealing |
1.0 |
Test Medium |
Water |
Intensity |
1.5 |
|
Working Pressure |
≤1.0Mpa |
Working Medium |
Slurry, slag, tailings |
