Model HV unloading solenoid valve is a direct-operated valve, which is applicable to one direction flow.
· Model HV unloading solenoid valve is used on the compressor of the freezer, cold store and air conditioning unit. It will automatically unload in accordance with the decrease of heat load so that it couldsave the compressor energy and extend the service life of compressor.
· The valve seat of Model HV unloading solenoid valve is well sealed with perfect sealing performance.
· Both packed and separated Model HV unloading solenoid valves are available and it means the valve body could be supplied separately from the solenoid.
Features:
· Only NC type solenoid valve is available.
· The max. Design temperature is 110C
· 10W high power solenoid and max. Operating pressure differential (MOPD) is 2.5 MPa.
· It is applicable to various compressors in freezer, cold store and air conditioning unit.
· The clamped joint solenoid is easy to be mounted or dismounted only with one screwdriver.
· The sealed solenoid has a long service life and it can be used even in an adverse circumstance
|
Item No. |
Connection |
Pressure differential to
Open Valve P(MPa) |
Max operating
pressure PB(MPa) |
KV factor
(M3/h) |
|
Inlet |
Outlet |
Min |
MOPD |
|
HTV3.2B |
Flanged Connection |
0.0 |
2.1 |
3.0 |
0.27 |
|
HTV2P |
3/8ODF |
3/8SAE |
0.0 |
2.5 |
2.8 |
0.16 |
