Tank Body
Shape Mono block Cylinder
Total Volume(m3) 38 CBM
Tanker Body Material 4 mm steel / High Tensile Steel Q610L
End plate 5 mm steel sheet/ High Tensile Steel Q610L
Manhole cover Aluminum alloy API manhole cover, ∮500mm ,4 sets with 4 breather valve Compartments 4 compartments
Bottom Valve 4 units Pneumatic Bottom Valve
Discharging valve 4"rubber hose, 2 pcs, 6m long
Discharging Pipe 4 sets ∮100mm discharging valves
| Chassis |
| Main Beams | Special design I beam, connected by bolts and nuts with tanker body, removable from tanker body for separate transportation; |
| Axle | 3 axles |
| BPW 12 Ton |
| Landing Gear | JOST brand Two-speed, manual operating, heavy duty landing gear |
| King Pin | JOST brand 2" bolt-in king pin |
| Suspension | Air Suspension |
| Pneumatic Braking System | WABCO RE 4 relay valve; T30/30+T30 Spring brake chamber; 40L air tanks. |
| Wheel rim | 11.75-22.5 wheel rim, 6 pieces |
| Tire | 385/65R22.5 super single tire, 6 pieces |
| Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
| Accessories | One standard tool box, one spare tyre and tyre carrier |
Hua-Win is a company with a tradition of over 50 years in the engineering industry and has aggregated a wide experience in this field. The main strategic program is focused on the production of trailers, tankers, dump trucks and other special vehicles. The company currently employs 1100 people and enjoys strong growth. Its turnover in 2007 is USD66.5 million and in 2008 it reached USD73.7 million. Hua-Win now ranks top 5 in special vehicle in China. The company' S total area is 430 acres and in 2011 its annual production ability will expand to 20, 000 units.
Hua-Win is customer orientated and manages its business processes with the dynamics, efficiency and reliability to reach high customer satisfaction ratings. The combination of modern technology and human oriental assures a strong and competitive position in both domestic and international market.
Hua-Win has set up 27 service centers throughout China to provide ready-service for its customers. Complete coverage of sales service greatly reduces the distance between Hua-Win and its customers. Anytime customers want, Hua-Win will be there with them.
Working with reliable local partners, Hua-Win now is a key player in North Africa (Algeria, Libya, and Egypt), East Africa (Tanzania, Kenya, Uganda and Malawi)West Africa (Nigeria, Ghana, and Senegal), Middle East (U. A. E, Saudi Arabia and Qatar) and South East Asia., and Senegal), Middle East (U. A. E, Saudi Arabia and Qatar) and South East Asia.
