Cast iron valves
Standard:EN,ANSI,MSS,DIN,BS,JIS
Certificate:ISO,CE,FM/UL
Pressure rate:PN4,PN6,PN10
Body materials:Grey iron,Ductile iron
Operation:level handle,hand,wheel,gear operation.
End:flanges,grooved end,thread,wafer
Type:Butterfly valves,Gate valve,Globe valve,Check valves,Ball valves,Strainer,Foot valves,Balance valve.
Size:2"-24"
Packing in poly-wooden cases.
Payment LC,TT,DP
Used for water,oil,gas etc.
Material of main parts |
| Part name | Material |
| J41T-16 | J41W-16 | J41H-16 | J41F-16 |
| Body bonnet | Cast iron | Cast iron | Cast iron | Cast iron |
| Stem | Carbon steel | Carbon steel | Carbon steel | Carbon steel |
| Disc | Cast iron bronze | Cast iron | Cast iron,stainless steel | Cast iron PTFE |
| Performance data |
| Type | Nomial pressure (MPa) | Testing | Working temperature | Suitable |
| Strength(water)(Mpa) | Sealing(water)(Mpa) |
| J41T-16 | 1.6 | 2.4 | 1.8 | ≤200°C | Vapour water |
| J41W-16 | 1.6 | 2.4 | 1.8 | ≤100°C | Oil |
| J41H-16 | 1.6 | 2.4 | 1.8 | ≤200°C | Vapour water |
| J41F-16 | 1.6 | 2.4 | 1.8 | ≤120°C | Vapour water |
| Outline and connection dimension |
| Type | Nomianal DN(mm) | Dimensions(mm) |
| L | D | D1 | D2 | b-f | n-Φd | H | Φ |
| J41T-16 J41W-16 J41H-16 J41F-16 | 15 | 130 | 95 | 65 | 45 | 14-2 | 4-14 | 184 | 98 |
| 20 | 150 | 105 | 75 | 55 | 16-2 | 4-14 | 190 | 98 |
| 25 | 160 | 115 | 85 | 65 | 16-2 | 4-14 | 207 | 98 |
| 32 | 180 | 135 | 100 | 78 | 18-2 | 4-18 | 216 | 126 |
| 40 | 200 | 145 | 110 | 85 | 18-3 | 4-18 | 250 | 126 |
| 50 | 230 | 160 | 125 | 100 | 20-3 | 4-18 | 270 | 152 |
| 65 | 290 | 180 | 145 | 120 | 20-3 | 4-18 | 310 | 152 |
| 80 | 310 | 195 | 160 | 135 | 22-3 | 8-18 | 350 | 240 |
| 100 | 350 | 215 | 180 | 155 | 24-3 | 8-18 | 365 | 240 |
| 125 | 400 | 245 | 210 | 185 | 26-3 | 8-18 | 430 | 300 |
| 150 | 480 | 280 | 240 | 210 | 28-3 | 8-23 | 450 | 300 |
| 200 | 600 | 335 | 295 | 256 | 30-3 | 12-23 | 556 | 300 |
We are one of the biggest manufacturers and exporters of Pipeline products in China. We supply butt-welding pipe fittings, stainless steel screwed pipe fittings, forged steel flanges, cast iron valves, cast steel valves, stainless steel valves, balance valves rubber expansion joint, and much more. With many years of effort and support from our valuable customers, these products have obtained a big marker share in the world. At present our products have been export to Asia(Singapore, Tailand, Saudi Arabia, Bahrain, Yemenm, Jordan)Europe(Gemany, Italy, Spain, France, Portudal, Poland)Africa(Egypt, , Camaroon, Morocco)America(USA, Chile, Peru, Panama, Brazil, Paraguary Mexico)
Our business policy is noted for four "F":
Quality First Reputation First.
Customer First Price Fair.
Friends, traders and manufacturers all over the world are welcome to join us establishing and developing business relations on the basis of equality and mutual benefit under the principle of "Provide The World Market With High Quality Goods And Best Service".
Any information, samples and drawing s that you can provide will facilitate us to make the correct supply to meet your special requirement.
