JIS 10k/20k Scs13 or CF3 Flange Floating Ball Valve
Price: |
US $ 30/Piece |
Trade Terms: |
FOB,CIF,EXW |
Min Order: |
10/Piece |
Pay Type: |
T/T,Western Union |
Design
These API/DIN Floating ball valve(2 piece type) are designed and manufactured to provide maximum service life
and dependability. All ball valve are full bore and meet the design
requirements of American Petroleum Institute standard API 608&API 6D,
British standard BS 5351 and generally conform to American Society of
Mechanical Engineers standard ASME B16.34 valves are available
in a complete range of body/bonnet materials and trims.
Applicable Standards:
STEEL BALL VALVES API 608/API 6D
STEEL BALL VALVES ISO 14313
FIRE SAFE API 607
ANTI STATIC API 608
STEEL VALVES ASME B 16.34
FACE TO FACE ASME B 16.10
END FLANGED ASME B 16.5
BUTTWELDING ENDS ASME B16.25
INSPECTION AND TEST,API 598/API 6D
Flanged Ball Valve product description: |
1.SIZE: DN15-DN300 |
2.Material: SS304,SS316,CF8,CF8M,CF3M,WCB |
3.Pressure: PN16/PN40 |
4.IS0 5211 direct mounting pad |
5. Media: Chemical media,Pulp,water,oil,gas |
6.Seat: SS316+STL,PTFE, |
7.Body: Investment Casing |
8.DIN PN40 (DN15~DN50) |
9.DIN PN16(DN65~DN300) |
10.Face to face DIN3202 |
11. Applicable temperature: -40C~180C |
12.locking device handle available |
13.Blot-out proof stem |
14.All size are full port |
15.Testing according to BS |
16.Anti-static debices for ball-stem-body |
Item | Parts | Material |
1 | Body | 304 | 304 |
2 | Cap | 304 | 304 |
3 | Ball | ASTM A351 CF8M | ASTM A351 CF8M |
4 | Seat | R-PTFE | R-PTFE |
5 | Stem | ASTM A182 F316 | ASTM A182 F316 |
6 | Body gasket | PTFE | PTFE |
7 | Thrust washer | R-PTFE | R-PTFE |
8 | Stem bearing | PTFE | PTFE |
9 | Packing | PTFE | PTFE |
10 | Gland | ASTM A182 F304 | ASTM A182 F304 |
11 | Belleville washer | ANSI 301 | ANSI 301 |
12 | Nut | ASTM A194 Cr8 | ASTM A194 2H |
13 | Locking device | ANSI 304 | ANSI 304 |
14 | Stop-lock-Cap | ANSI 304 | ANSI 304 |
15 | Handle | ANSI 304 | ANSI 304 |
16 | Stop Blot | ASTM A193 B8 | ASTM A193 B7 |
17 | Handle sleeve | Plastic | Plastic |
18 | Anti-static | ANSI 304 | ANSI 304 |
Prod Model: |
Q41F-10K-DN50 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Connection Form: |
Flange |
Channel: |
Straight Through Type |
Structure: |
Floating Ball Valve |
Type: |
Floating Ball Valve |
Material: |
Stainless Steel |
Application: |
Water Industrial Usage |
China zhongya valve Co., Ltd. is a collection research and development, manufacturing, sales and integrated high-tech enterprises. The company is located in NO. 3511 Yongqiang Avenue Longwan District Wenzhou city Zhejiang China...The company introduces advanced technology from abroad, the modern scale production, and equips Germany processing center, Taiwan CNC machine, super precision vertical lathe, automatic painting line and special equipment, machining center, CNC machine tools, special molding, slinging cleaning, passivation treatment, ultrasonic cleaning equipment and a variety of valve pressure testing equipments. As well as equipped with photoelectric direct reading analyzer, thickness tester, radiographic, ultrasonic and liquid penetrant ect, non-destructive testing equipment to ensure that the company's products can be manufactured strictly in accordance with clients'requirements of related standard, to meet the different demands of them.
The company mainly in producing gate valve, globe valve, ball valve, check valve, butterfly valve, hydraulic control valve, supply and drainage water equipment and a variety of special non-standard special valves.
The company implements API (USA) and EN (European Union), ISO (international organization for standardization), BS (British), JIS (Japan) and GB (China) and other major advanced industrial countries and the latest standards of the national standard designing production. Valve body materials are used of carbon steel, alloy steel, chrome molybdenum steel, stainless steel, low-temperature steel, high-temperature steel, nickel base and cobalt base alloy and other materials, and materials specified by the user. Products are widely used in petroleum, chemical, natural gas, coal chemical industry, electric power, shipbuilding, pharmaceutical, paper making, beer industry, food, building, water supply, prevent pollution, and a large number of them are exported to the United States, Europe, Russia, Middle East, Japan, South Korea and southeast Asia and other regions.
