Nominal Diameter: DN15-50
Pressure Range: 0-10 bar
Operating Temp: -10C - +180C
Environment Temp: -10C - +60C
Body Material: Stainless steel
Sealing: PTFE; NBR; EPDM
Actuator Body: PA Stainless steel
Control Pressure: 3 bar-8 bar
Feature: Double acting, Single acting
All of our products are manufactured in accordance with such industrial standards as ISO, DIN, 3A, IDF, SMS, JIS and GB, and the quality fully meets the specifications and requirements of FDA/GMP.
|
DNNominal diameter |
out-form dimension |
Speediness disc dimension |
Actuator
specification |
|
L |
L1 |
L2 |
D |
|
15 |
108 |
64 |
60 |
34 |
Φ50 |
|
20 |
118 |
64 |
60 |
50.5 |
Φ50 |
|
25 |
127 |
80 |
60 |
50.5 |
Φ63 |
|
32 |
146 |
80 |
77 |
50.5 |
Φ63 |
|
40 |
159 |
101 |
77 |
50.5 |
Φ80 |
|
50 |
191 |
101 |
77 |
50.5 |
Φ80 |
