Product Details:
Gate Valve is used when the need exist for a device that allows an interruption or cut off the flow of a fluid. It is not recommendable to use Gate Valves for flow modulation as the high velocity of the through may result in erosive damage to the wedge and seats when the valve is partially opened. Under normal operating conditions, the valve should remain either fully open or fully closed. Gate Valve is widely used for the medium of water, steam, air, oil, petroleum and petroleum products, nonaggressive fluids.
Applicable Standard
Design Standard: API 600
Face to Face: ASME B16.10
End Flange: ANSI B16.5, ANSI B16.47
Butt welding Ends: ANSI B16.25
Inspection and Test: API 598
Design Features
Standard port design
OS&Y, outside and screw
Bolted bonnet, back seal structure
Flexible wedge, fully guided
Thread or welded seat
Extended stem design for low temperature
Flanged or butt-welding Ends
|
Size: |
2" ~40 " |
|
Rating: |
ANSI 150lb ~ 2500lb |
|
Body Materials: |
WCB, WC6, LCB, CF8, CF8M, CF3, CF3M, etc. |
|
Operation: |
Hand wheel, Gear, Electric, Pneumatic |
|
|
Please contact us for other sizes, pressures and materials. |
JCIN VALVE is a leading manufacturer and supplier of valves for Oil, Gas, and Power Generation industries.
The main products include Gate Valves, Globe Valves, Check Valves, Butterfly Valves, Dual Plate & Strainers, in forged or cast steel. Our product range starts from 1/2" and extends to 36" valves with pressure ratings ANSI / ASME Class 150 to 2500 Lbs, and DIN PN 16 to PN 100.
The highest quality and variety of used materials (Carbon Steels, Low Temperature Carbon Steel, Alloy Steels, Stainless Steels, and other special alloy steel according to ASTM & ASME) can satisfy all the requirements of the Chemical, Petrochemical and Power Plants, Oil and Gas, Off-Shore & On-Shore, Refining, Ship Building, Water Treatment & Energy Generation.
JCIN VALVE's annual sales include 80% for international market, which mainly exported to South Africa, Italy, Poland, Spain, and South America area, we are strive to become a global brand of industrial valve.
At JCIN VALVE, Our main target is to offer a high quality product and service to ensure the highest degree of satisfaction and fidelity of our customers.
JCIN VALVE---Your honest partner on Industrial valve.
