Limestone Crusher Plant
We can supply limeStone crusher plant by the capacity of 50-500 tons per day. Limestone production flow mainly include: Limestone crusher and transportion, raw material pre-homogenizing, raw material preparation, raw material homogenizing, warm-up decomposition, sintering clinker Stone crushing plant, Stone crusher, limestone grinding, limestone packaging and so on.
The design of a stone crushing production line is usually decided by several factors:
1) Raw materials to be crushed
2) The hardness, percentage of Si, moisture percentage of the raw materials
3) The average size of the raw materials before entering into the crushing system
4) Requested product sizes, percentage of the sizes, and their usage
5) Hour capacity of the crushing line
For the Limestone crushing production lines: 30-50tph, 50-80tph, 80-120tph, 120-200tph, 200-300tph, 300-400tph, 400-500tph, we here recommend three proposals:
1: Vibrating feeder + primary Jaw crusher + Impact crusher + Vibrating screen + belt conveying system + control system
2: Vibrating feeder + primary Jaw crusher + fineness Jaw crusher + Impact crusher(optional) + Vibrating screen + belt conveying system + control system
3: Vibrating feeder +primary Jaw crusher + Cone crusher + Impact crusher(optional) + Vibrating screen +belt conveying system + control system In the above proposals, the main difference is the secondary crusher: Using Impact crusher or using fineness Jaw crusher(plate pressing principle), or Compound Cone crusher(plate pressing principle).
|
Model |
Feed inlet
size(mm) |
Max inlet
size(mm) |
Capacity
(t/h) |
Electric
power(kw) |
Overall size
LxWxH(mm) |
Weight
(t) |
|
PE150× 250 |
150× 250 |
125 |
1-5 |
5.5 |
875× 758× 850 |
0.81 |
|
PE250× 400 |
400× 250 |
210 |
5-20 |
15 |
1450× 1315× 1296 |
2.8 |
|
PE400× 600 |
600× 400 |
340 |
16-65 |
30 |
1565× 1732× 1586 |
6.5 |
|
PE500× 750 |
750× 500 |
425 |
45-100 |
55 |
1890× 1916× 1870 |
10.1 |
|
PE600× 900 |
900× 600 |
500 |
50-120 |
55-75 |
2305× 1840× 2298 |
15.5 |
|
PE750× 1060 |
1060× 750 |
630 |
52-180 |
110 |
2450× 2472× 2840 |
28 |
|
PE900× 1200 |
900× 1200 |
750 |
140-260 |
110 |
3200x3050x2950 |
54.5 |
|
PE1000× 1200 |
1000× 1200 |
850 |
315-342 |
110 |
3335x3182x3025 |
57 |
|
PE1200× 1500 |
1200x1500 |
1020 |
400-800 |
160 |
4200x3750x3820 |
100.9 |
|
PEX250× 1000 |
1000× 250 |
210 |
16-52 |
30-37 |
1530x1992x1380 |
6.5 |
|
PEX250× 1200 |
1200× 250 |
210 |
20-60 |
37 |
1900x2192x1430 |
7.7 |
