Inverted pressure balance lubricated Plug Valve Features:
Inverted pressure balance lubricated plug valve acc to ansi is applicable to the cutting and connection of pipe lines medium that are used in various industries such as petroleum, chemical, pharmacy, chemical fertilizer, electric power industry etc under nominal pressure Class 150--1500LB and working temperature --29oC---180oC
Inverted pressure balance lubricated Plug Valve Structural:
The product has reasonable structure, reliable sealing, excellent performance.
Opening&Closing of the valve is carride out while the sealed surface is taken off, so it will not cause abrasion on the sealed surface.
The materials of the parts and sizes of flanges can be reasonably configured acccording the actual operation condition of the requieements of the customersm, so as to meet the various needs of engineering.
Inverted pressure balance lubricated Plug Valve Technical Specification:
Structural feature: Bolted bonned, OS&Y, BG.
Operation: Hand wheel, worm gear, Elecric-actuated
Design standard: API 599, API 6D
Face to Face: ASME B 16.10
Flange end: ASME B 16.5
Test &Inspection: API 598, API 6D
Inverted pressure balance lubricated Plug Valve specification:
Size: 1/2 "--14"
Class 150--900LB
Temperature: --29 oC--180oC
Medium: Oil, Water, Gas.
Material: ASTM A216 WCB, A351 CF8, CF8M, CF3, CF3M. A182 F304, F316, F304L, F316L.
Established in 1996, Luofu Valve Group Zhejiang Zhonggong Valve Co., Ltd is located in Wenzhou City, Zhejiang P. R 325105, China.
Main Products:
1. API/ANSI Standard Valve: Butterfly Valve, Gate Valve, Safety Valve, Globe Valve, Check Valve, Ball Valve, Plug valve
2. DIN standard: Gate valve, globe valve, strainer
3. GB Standard: Butterfly Valve, Gate Valve, Safety Valve, Globe Valve, Check valve, Control Valve, Water Control Valve, ball valve, plug valve
4. Flange and strainer
5. Bellows type valve: Globe valve, safety valve, gate valve, strainer
Honors:
1. API 6D
2. ISO9001: 2000
3. CE Certificate
4. AZ Certificate
5. Invent Patent (Patent No.: ZL 99 1 13657.8)
6. Audited Supplier (Trustworthy Supplier Members on Made-in-China. com)
Nominal diameter (DN): 15-4500 mm(1/2"-180");
Nominal Pressure (PN): 1.0Mpa-32Mpa(150lb-3000lb);
Material of body: WCB, WC6, WC9, CF8, CE3, CF3M. CF8M, etc.
Standard: GB, DIN, JIS, ANSI, API
The company has excellent mechanical processing equipment and modernized inspection& testing equipments more than 66 sets.
Zhonggong Valve Co., Ltd is experienced in the design and manufacture of valves and enjoys a high reputation in the valve industry. Now it has become the material equipment company of SINOPEC, the first-class network supplier of China National Petroleum Corporation, the member unit of China Ocean Petroleum Corporation, Shengli Oil Field, China Water &Electric Power Company, etc.
