Lug Type Pneumatic Knife Gate Valve
Price: |
US $ 105/Piece |
Trade Terms: |
FOB,CIF |
Min Order: |
1/Piece |
Pay Type: |
L/C,T/T,Western Union |
Lug type pneumatic knife gate valve
| 1. Product name | Pneumatic JIS Standard Knife Gate Valve | 2. Brand name | GL valve | 3. Pressure | PN10&Class150&10K | 4. Size | DN50-DN1200&2"-48"&50A-1200A | 5. Body material | DI(GGG40)&SS(304,316)(solid solution treatment) | 6. Gate material | SS304&SS316(solid solution treatment) | 7.Seat material | EPDM&Metal&Viton&NBR | 8.Packing material | PTFE& Silicone | 9.Support plate | A 36+epoxy plate | 10.Operation | Handwheel, bevel gear, DA pneumatic, electric,etc. | 11.Packing | Plywood case | 12.Payment | T/T, L/C, West union 30% before production, balance before shipment. | 13.Quality | Every process is inspected by our QC team | 14.Sample | Ready samples are available for inspection reference |
|
2. Brand name | GL valve |
3. Pressure | PN10&Class150&10K |
4. Size | DN50-DN1200&2"-48"&50A-1200A |
5. Body material | DI(GGG40)&SS(304,316)(solid solution treatment) |
6. Gate material | SS304&SS316(solid solution treatment) |
7.Seat material | EPDM&Metal&Viton&NBR |
8.Packing material | PTFE& Silicone |
9.Support plate | A 36+epoxy plate |
10.Operation | Handwheel, bevel gear, DA pneumatic, electric,etc. |
11.Packing | Plywood case |
12.Payment | T/T, L/C, West union 30% before production, balance before shipment. |
13.Quality | Every process is inspected by our QC team |
14.Sample | Ready samples are available for inspection reference |
Prod Model: |
GKA673 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Body: |
Stainless Steel+Solid Solution Treatment |
Gate: |
Ss304/Ss316+Solid Solution Treatment |
Stem: |
ANSI 1045+Chrome Plated |
Seat: |
EPDM/Metal/Viton/NBR |
Support Plates: |
A36+Epoxy Baked |
Packing Gasket: |
PTFE+Silicone |
Color: |
Black as Standard,Others on Request |
Place Of Origin: |
Zhejiang,China |
Certificate: |
CE,ISO,Ts etc. |
Material: |
Stainless Steel |
Thread Position Of Valve Rod: |
Inside Gate Valve |
Application: |
Household Usage |
Type: |
Knife |
Connection Form: |
Lug |
Seal Surface: |
Knife |
Standard: |
Ans for Knife Gate Valve |
Established in 1992 and re-established in 2004, Zhejiang Guanli Valve Co., Ltd. Covers an area of 7, 500 square meters located at Dongou Industrial Zone in Wenzhou. Our company is located in Wenzhou, only 500 kilometers from Shanghai Pudong Airport.
We are a professional manufacturer of industry valves according to API, DIN, JIS standards. Our products include knife gate valves, ball valves, gate valves, globe valves, check valves and butterfly valves. Our valves are made with materials of WCB, WC6, WC9, LCB, 304, 316, 304L, 316L and F51. They are widely used in many fields, such as petroleum, chemical, natural gas, power, feed water, steel and metallurgy.
If you are interested in any of our products, please feel free to contact us for more information.
