Motor Actuated Needle Valve

Motor Actuated Needle Valve
Price: US $ 8700/Piece
Trade Terms: FOB,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T
Flow control valve specification

This valve modulates the flow by the plug that reciprocates in the centerline direction of the pipeline to increase or minish the outlet section. There are four types of outlets: E type is suitable to throttle the flow; F type is suitable to open and close; S&L type are suitable to modulate the flow. The motor operation type is suitable to be used as automatic modulation type to modulate the flow in the pipe line.

Suitable mediumwater, sea water
Standard:Q/TF-B27L. 01, BS, ISO, DIN
Nominal pressure:PN0.6-1.6MPa
Nominal diameter:DN250-2000mm
Suitable temprature:≤ 80
Main material:grey cast iron, ductile cast
iron, alloy cast iron
Flange dimensionBS4504  ISO2531, ISO7005
and other standards conforming to the requirements
Sealing material:rubber-stainless steel
Leakage:GB/T 13927 (IS05208)Class A
Driving type:manual, motor, hydraulic
MATERIALS OF MAIN PARTS

Name of parts

Material of parts

Body flange

Cast iron/ductile iron/carbon steel

Piston gate

Stainless steel

Stem

Stainless steel

Body sealing ring

Brass

Piston gate sealing ring

NBR



Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Dn250-2000mmpn.0.6-1.6mpa: Grey Cast Iron, Ductile Cast
Stem Thread Position: Outside Screw Stem Globe Valve
Sealing Form: Bellows Globe Valve
Application: Needle Type Globe Valve
Power: Hydraulic
Material: Casting
Pressure: Low Pressure
Standard: Standard
Media: Water
Media Temperature: Low Temperature
Tieling Water Valve Co., Ltd. is one of the key enterprises after the former Tieling Valve Works was reformed. It is the largest low pressure big diameter valve, penstock manufacturing base. It has a history of more than 70 years, it is named as advanced new and high-tech enterprise.

The registered capital is 65 million. We have 180 staff which include 2 senior professional title technicians; 15 middle professional title technicians; 40% of the staff graduated from the college. Our company occupies an area of 18558 m2 and a building area of 7800 m2. We have 4M, 2.5M, 1.25M vertical lathes, T111 boring machine, TP*6111B/2 horizontal boring and milling machine, TP*6213 stand boring and milling machine, crane, fork truck, Z3080*25, Z30100*31 large radial drilling machine, plate shearing machine, cutting machine, planning machine, universal tool grinding machine, plate bending area of 7800 m2. We have 4M, 2.5M, 1.25M vertical lathes, T111 boring machine, TP*6111B/2 horizontal boring and milling machine, TP*6213 stand boring and milling machine, crane, fork truck, Z3080*25, Z30100*31 large radial drilling machine, plate shearing machine, cutting machinerolls. There are more than 80 machining equipments and cranes of 32/5 T, 20T and 5T. We can produce gray cast iron, ductile iron, low alloy iron valves, steel penstock, cleaning machine, different kind of wind gates, strainers, and pipe fittings and valve actuators. The annual capacity (production value) is RMB 50 million.

The main products: Butterfly valve, gate valve, check valves, air release valve, rotating strainer, comb type cleaning machine, grating, steel penstock, cool and hot isolating gate, guarding gate, regulating shrinkage hole, inserting gate; The suitable medium: Clean water, sewage water, sea water, air, high temperature stove air, gas, steam and different acid and alkali liquid; Suitable temperature: -40º C to 600º C; Suitable pressure: 0.01MPa~2.5MPa; Nominal diameter: DN50-DN3000, actuating methods: Manual, motor, pneumatic, hydraulic, motor& hydraulic. According to the customer' S requirements we can design and manufacture the products conforming to GB, JB, ISO, DIN, BS, API, ANSI. The products are widely used in water power plant, thermal power plant, water plant(city water supplying and distributing), sewage treatment plant, gas, airline, metallic, petroleum and chemical, mine, water power.

Our products have been applied in many projects such as: Beijingyanshang Petroleum &Chemical, Yuanbaoshan Power Plant, Tangshansanyou Thermal Power plant Co., Ltd., Fuxin Power Plant, Anhuipingwei Power Plant, Guodian Puyang Thermal Power Plant Co., Ltd., Jilin Songyuan Oil Refining Plant, Jinxi Petroleum & Chemical Co., Ltd., Jinzhou Power Plant, Guangdong Liede Water Plant. Our company has the right of importing&exporting, some of the products have been exported to USA, Canada, England, Turkey, Spain, Pakistan, Iran, Iraq, Singapore, Thailand, Malaysia, Cambodia, Syria. South Africa, Nigeria, Egypt, Tanzania and other countries.

We have gained the belief and good evaluation from the foreign and domestic customers for our Good product quality and perfect after sale service.

Sincerely welcome the domestic and foreign clients to our company for visiting and negotiation. We will provide you with best products and perfect service.

Our quality policy: Customer is the center, pursuit excellence; Quality first, credibility supreme.
