Quick Details
| Standard or Nonstandard: | Standard | Structure: | Gate | Pressure: | Low Pressure |
| Power: | Manual | Material: | Casting | Temperature of Media: | Normal Temperature |
| Media: | Water | Port Size: | DN50 | Place of Origin: | Hebei, China (Mainland) |
| Brand Name: | TJL | Nominal diameter:: | DN50-DN300 | Working pressure:: | 10Bar/16Bar |
| Valve Design:: | DIN3352 | Face-to-face:: | DIN 3202-F5/ SABS664 | Flange accommodation:: | JISO4422 |
| Test Standard:: | ISO 5208 |
Nominal diameter: DN50-DN300
Working pressure:10Bar/16Bar
Valve Design: DIN3352
Face-to-face: DIN 3202-F5/ SABS664
Socket ends Dimensions:ISO4422
Test Standard: ISO 5208
Nominal Diameter DN | DN50(2'') - DN 300(12'') | MM |
Nominal Pressure PN | 1.0 | 1.6 | Mpa |
Test Pressure | Shell | 1.5 | 2.4 |
Sealing | 1.1 | 1.76 |
Working Temperature | -10~100 | ºC |
Suitable Medium | Water,Sewage,Sea Water,Air,Foodstuff,Oil etc. |
No. | Part | Material |
1 | Body | GGG50 |
2 | Wedge | GGG50+ EPDM/NBR |
3 | Wedge Nut | Brass |
4 | Stem | Stainless Steel |
5 | Bonnet | GGG50 |
6 | Back Sealing O-ring | EPDM/NBR |
7 | O-ring | EPDM/NBR |
8 | Stuffing Nut | Brass |
9 | Gland Flange | GGG50 |
