Pump features
Forged brass cylinder
Anodized crankcase
Ceramic plungers
German parker water seal
Fixed rate chemical injector
Out-returning unloader
Pressure adjustable
Quick connect outlet
Optional
Pressure gauge
Thermal relief valve
Adjustable chemical injector
3WZ-1507C
Bore (mm): 15
Stroke (mm): 7
Max. Pressure (bar): 180
Flow (L/min): 10.7
RPM: 2900
Power Required: 3.7kw
3WZ-1508C
Bore (mm): 15
Stroke (mm): 8
Max. Pressure (bar): 206
Flow (L/min): 12.3
RPM: 2900
Power Required: 4kw
3WZ-1509C
Bore (mm): 15
Stroke (mm): 9
Max. Pressure (bar): 220
Flow (L/min): 13.8
RPM: 2900
Power Required: 5.5kw
3WZ-1510C
Bore (mm): 15
Stroke (mm): 10
Max. Pressure (bar): 206
Flow (L/min): 15.3
RPM: 2900
Power Required: 5.5kw
3WZ-1512C
Bore (mm): 15
Stroke (mm): 12
Max. Pressure (bar): 220
Flow (L/min): 18.4
RPM: 2900
Power Required: 7.5kw
Lutian Machinery Co., Ltd. Was founded in August, 2002, specialized in researching, developing and
Manufacturing high pressure washers, generators and water pump. Our company is the Vice-chairman Unit of China Agricultural Machinery Industry Association and National Director Unit for
Plant Protection&High Pressure Washer Field. Our company insists on the scientific development
Concept. Depending on advanced business concept, lean management, leading technology, high
Quality products and services, our company grows stronger year by year. At present our company
Has the staff of almost 1000 people, factory building area of 100000 square meters and property of more than 280 million RMB. Our sales network covers more than 60 countries and regions in Europe, North and South America, Southeast Asia and Middle East, etc. The annual turnover is more
Than 600 million RMB and export value is more than 80 million us dollars, We are one of the biggest
High pressure washer manufactures and exporters in China.
