Pn16 Ductile Iron Casting Ball Valve

Pn16 Ductile Iron Casting Ball Valve
Price: US $ 10-1000/Set
Trade Terms: FOB,CFR,CIF
Min Order: 10/Set
Pay Type: L/C,T/T,D/P,Paypal,Western Union
Details of SYI Ductile Iron Ball valve:

1) Standards:
A. ANSI
B. API608
C. API6D
D. BS

2) Test Standard: API598, API6D

3) Face to face is according to ANSI B16.10

4) Flange drilling is according to ANSI B16.5a

5) Material:
A. Cast Iron
B. Stainless steel
C. Carbon Steel
D. WCB

6) Operation: Manual, Electric actuator
7) Media: Water, Oil, Gas etc.

8) Working Pressure: 150LB-600LB

9) Working dimensions: DN15-DN250

10) Coating: Fusion Bonded Epoxy Powder Coating

More information is available upon receipt of your enquiry.

You will get our quick reply!
Part Name Material
Body ASTM A216 WCB

ASTM A351 Cf8

Disc and Yoke WCB Cf8 CF8M Monel
Hinge pin F6a F304 F316 Monel F304
Disc face 13Cr 13Cr STL 304 STL 316 STL Monel 304 304 STL
Seat ring face 13Cr 13Cr STL 304 STL 316 STL Monel 304 STL STL
Part Name Material
Body ASTM A351 Cf3

ASTM A351 CF8M ASTM A351 Cf8

Disc and Yoke
Hinge pin F304L F316L F316L
Disc face 304L 304L STL 316 316 STL 316L 316L STL
Seat ring face 304L STL STL 316 STL STL 316L STL STL


Prod Model: DN 80
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Surface: Powder Coating/Acid Pickling/Paint
Connection Form: Outside Thread
Material: Carbon Steel
Seal Surface: Parallel Gate Valve
Thread Position Of Valve Rod: Outside Gate Valve
