Foam packin inside, one carton box outside
Then put all carton box in one strong plywood case for sea transport
VS series pneumatic actuators statement of usage and selection
Through research development and design XM series pneumatic actuators incorporate the latest technology materials and innovative idea. The product proudly boasts the following features.
Full conformance to the latest specifications: ISO5211, DIN3337 and VDINDE-3854, NAMUR.
The extruding high intensity aluminum body possesses a honed internal surface coated with hard anode oxygenation for long life. Low coefficient of friction and swift performance.
Excellent compact and modernized construction along with multi specifications makes the selection both economic and beneficial.
All acting surface adopt high quality bearing resulting in low friction, high cycle life, and no noise
The two independent external stroke adjustment bolts can easily and precisely adjust ± 5° At both open and close directions.
Same outline actuators have the functional modes of double acting and single acting (Spring -Return). The Spring-Return has the normally-open and normally-close styles.
Multi function indicator with NAMUR is convenient for mounting accessories.
Pre-compressed load spring is convenient for safe mounting and tear down procedures.
Die-casting aluminum pistons and end caps have high intensity and light weight.
Different O-rings materials are available for high and low temperature.
Solenoid valves are easily mounted without any connecting plank.
VS series pneumatic actuated butterfly valve:
Driving: Pneumatic Actuator
Valve: Center line-type butterfly valve
Valve Size: 1-1/2"~40" (DN15~DN1000)
Body Material: FC, FCD, WCB, CF8, CF8M
Disc Material: FCD, WCB, CF8, CF8M, CF3M
Seat Material: EPDM, NBR, VITON
Rating: PN10, PN16, ANSI: 150#, 300#
Connection: Wafer, Lug, Flange
Shanghai Xunhe Electromechanical Co., Ltd., is an enterprise incorporate research, development, manufacturing and sale service. We import technology from Demark and with the unique design, perfect manufacturing technology and reliable performance; VESON series products got a worldwide excellent reputation. Up to now, VESON products have an exclusive application in Oil & Gas, Refining, Petrochemical, Chemical Processing, Metallurgy, Power Plant, Construction, Thermal, Water supply.
We are a professional manufacturer & wholesale of VESON series pneumatic actuator, electric actuator, accessories for pneumatic actuator (limit switchbox, solenoid valve, positioner, air filter regulator, manual override), pneumatic actuated ball valve/ butterfly valve, manual operated ball valve/ butterfly valve and control valve etc. At the same time, the company is certified by ISO9001: 2000 quality management system. We posses the solid technology support and many experts, in which 2 senior engineers, 6 engineers, account for 34% of the staff.
We have advanced equipment, leading and professional management team. Quality is our life and serving customer is our purpose. The professional sale and service team provide customer with the best solution of valve control automation.
