Pneumatic Butterfly Valve
| Price: |
US $ 200/Piece |
| Trade Terms: |
FOB |
| Min Order: |
1/Piece |
| Pay Type: |
T/T |
Hangzhou xiyuena automatic controlled equipment Co., Ltd. is a high-tech enterprise which is specialized in research, development, production of intelligent electrically-operated actuator and electrically-operated regulating valve. With great technical support of scientific research organizations of higher education institutes, and absorption of German technologies, it has produced first class electrically-operated valve actuator.
Product Description
Main Technique Parameters
Input signals:
4mA~20mA; 1VDC~5VDC;
2mA~10mA; 0.5VDC~2.5VDC;
20V~60VDC or 30V~220 VAC electricity signal;
Power supply:
380VAC/50Hz; 220VAC/50Hz
Accuracy: ≤ 1%
Deadband: 0.1~9.9% of travel between open and close limit positions
Enclosure: IP68
Anti explosion nark: ExdIICT4
Ambient humidity: ≤ 95%
Product Description
1. If it dosen't select this function, this type will be only used in switch control.
2. If only select this function, the valve location of output 0-1000Ω Resistance signal.
3. Input 4-20mA, Output 4-20mA, for adjusting the acting pattern, if it select this function, it must simultaneously select POT function.
4. Input the control of the passive contact, Output 4-20Ma, if it select this function, it must simultaneously select POT function.
5. Input the control of active contact(220VAC control), Output 4-20mA, if it select this function, it must simultaneously select POT function.
|
Model |
Size |
|
|
|
|
|
|
|
|
|
|
|
|
|
A |
B |
C |
D |
E |
F |
H |
O |
L |
M |
P |
R |
|
PSL201 |
|
|
|
|
|
|
|
|
|
|
|
|
|
PSL202 |
|
|
|
|
|
|
|
|
|
|
|
|
|
PSL204 |
459 |
237 |
116 |
35 |
20 |
50 |
& phi; 16 |
& phi; 100 |
100 |
M16 |
& phi; 20 |
& phi; 177 |
|
PSL208 |
|
|
|
|
|
|
|
|
|
|
|
|
|
PSL210 |
490 |
234 |
111 |
35 |
20 |
50 |
& phi; 16 |
& phi; 100 |
100 |
M16 |
& phi; 20 |
& phi; 182 |
|
PSL312 |
|
|
|
|
|
|
|
|
|
|
|
|
|
PSL314 |
|
|
|
|
|
|
|
|
|
|
|
|
|
PSL316 |
|
|
|
|
|
|
|
|
|
|
|
|
|
PSL320 |
|
|
|
|
|
|
|
|
|
|
|
|
|
PSL325 |
788 |
450 |
174 |
42 |
25 |
100 |
& phi; 20 |
& phi; 120 |
155 |
M20 |
& phi; 32 |
& phi; 228 |
|
Product Description |
|
1. If it dosen't select this function, this type will be only used in switch control. |
|
2. If only select this function, the valve location of output 0-1000Ω Resistance signal. |
|
3. Input 4-20mA, Output 4-20mA, for adjusting the acting pattern, if it select this function, it must simultaneously select POT function. |
|
4. Input the control of the passive contact, Output 4-20Ma, if it select this function, it must simultaneously select POT function. |
|
5. Input the control of active contact(220VAC control), Output 4-20mA, if it select this function, it must simultaneously select POT function. |
|
|
|
Infrared remote control |
|
The series products have passed "CE" auditing and ISO9001: 2008quality management system certificate. |
|
Model |
Max stroke |
Max thrust |
Speed |
Motor protection |
Wire Connection |
Manual Operation |
Protection Class |
Power |
Weight |
|
(mm) |
(KN) |
(mm/s) |
(W) |
(Kg) |
|
PSL201 |
50 |
1 |
0.4 |
Allowlockedrotor |
M20× 1 |
Handwheel |
IP67 |
35 |
5.5 |
|
PSL202 |
50 |
2 |
0.4 |
Allow lockedrotor |
M20× 1 |
Handwheel |
IP67 |
40 |
5.8 |
|
PSL204 |
50 |
4 |
0.4 |
Allow lockedrotor |
M20× 1 |
Handwheel |
IP67 |
45 |
6 |
|
PSL206 |
60 |
6 |
0.4 |
Allow lockedrotor |
M20× 1 |
Handwheel |
IP67 |
80 |
8 |
|
PSL208 |
60 |
8 |
0.4 |
Allow lockedrotor |
M20× 1 |
Handwheel |
IP67 |
80 |
8 |
|
PSL210 |
60 |
8 |
0.4 |
Allow lockedrotor |
M20× 1 |
Handwheel |
IP67 |
80 |
8.2 |
|
PSL310 |
65 |
10 |
1 |
Thermoswitch |
M20× 1 |
Handwheel |
IP67 |
130 |
22 |
|
PSL312 |
65 |
12 |
1 |
Thermoswitch |
M20× 1 |
Handwheel |
IP67 |
130 |
22 |
|
PSL314 |
65 |
14 |
1 |
Thermoswitch |
M20× 1 |
Handwheel |
IP67 |
130 |
22 |
|
PSL316 |
100 |
16 |
1 |
Thermoswitch |
M20× 1 |
Handwheel |
IP67 |
135 |
22 |
|
PSL320 |
100 |
20 |
1 |
Thermoswitch |
M20× 1 |
Handwheel |
IP67 |
140 |
23 |
|
PSL325 |
100 |
25 |
1 |
Thermoswitch |
M20× 1 |
Handwheel |
IP67 |
140 |
23 |
| Prod Model: |
SPL-208 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| 4-20mA: |
220VAC 110VAC 12VDC 24VDC |
| Size: |
1-20 Inch |
Hangzhou Xiyuena Automatic Controlled Equipment Co., Ltd. is a High-Tech Enterprise Which Is Specialized in Research, Development, Production of Intelligent Electrically-Operated Actuator and Electrically-Operated Regulating Valve. with Great Technical Support of Scientific Research Organizations of Higher Education Institutes, and Absorption of German Technologies, It Has Produced First Class Electrically-Operated Valve Actuator.
This Product Adopts Intelligent Control Circuit, and Is Able to Realize Self Diagnosis and Adjustment. The Working Status Is Shown in The LCD Display. Meanwhile, It Has Advantages Such as Strong Applicability, Full Function, Extremely Accurate Control, Easy Operation, Friendly Man-Machine Interface etc. It Can Be Widely Used as Valves in Fields Such as Chemical Industry, Power, Pharmacy, Metallurgy, Petroleum, and Switch Control and Regulation Control of Pipes. Besides, It Has Solved Shortcomings of Similar Domestic Products, Such as Slow Response, Complicated Structure, Large Volume and Easy to Fail.
The Company Will Take Technology Innovation and Management Innovation as Two Wings for Its Development. What's More, It Will, Through Strategic Cooperation with Domestic and Foreign Suppliers as Well as Social Technology Development, Consultation Institutions and Relevant Industrial Partners, to Realize The Goal of "Win-Win".
Company Concept: Insist on Serving The Customers and Creating Value for Them. Upholding The Modern Enterprise Spirits of "Work out Quality Products with Good Management, to Win Customers with Outstanding Service", It Constantly Reinforces Its Internal Regulation and Management. Besides, It Applies Modern Flow Reconstruction Mode, Establishes Effective System, and Consolidates Quality Tracking to Produce Quality and Advanced Products.
Company Service: to Establish Modern Market Operation Mode and Service Customers with High Quality Is Our Starting Point. to Effectively Gain Benefits for The Partners and to Make Maximum Use of Their Resources, The Company Will Think in The Shoes of The Customers, Proactively Utilize The Human Resources, Technologies and Equipment of The Company, to Provide Full-Round Service and Best Solution for The Customers on The Basis of Co-Development and Win-Win Strategy. as for Customer Needs, The Company Always Provide Full-Process Tracking From Order Placing, Production to Distribution, Thus to Ensure Satisfaction of Customer Needs to The Utmost.
Company Products: Have Passed Testing of The Automation Instrument Product Quality Supervision and Testing Center Under The Ministry of Machinery and Industry. All The Technical Performances Comply with National Standards. All The Products Are Produced According to Requirements of GB/T4213-1992. Meanwhile, We Also Produce Various Non-Standard Industrial Automation Flow Control Valve for Broad Customer.
