APPLICABLE STANDARDS:
Design: JIS B 2032, ANSI, GB
Face to Face: JIS B 2002 46, ISO 5752 20, API, GB
Wall Thickness: JIS ANSI GB
Inspection & Testing: JIS B 2032, API, GB
SPECIFICATIONS:
Working Pressure: 1.0-1.6MPa
Temperature Range: 0~120° C (EPDM); 0~60° C (NBR)
|
Diameter |
Size(mm) |
|
mm |
inch |
PN |
D |
L |
H 1 |
H 2 |
Double acting pneumatic |
Single acting pneumatic |
Electric |
|
H 3 |
A1 |
H 3 |
A2 |
H 3 |
A3 |
|
50 |
2 |
10/16 |
125 |
42 |
57 |
140 |
96 |
145 |
115 |
195 |
105 |
72 |
|
65 |
2-1/2 |
10/16 |
145 |
44 |
64 |
153 |
115 |
158 |
137 |
217 |
102.5 |
160 |
|
80 |
3 |
10/16 |
160 |
44 |
73 |
159 |
115 |
158 |
137 |
217 |
102.5 |
160 |
|
100 |
4 |
10/16 |
180 |
50 |
88 |
178 |
137 |
177 |
147 |
258 |
102.5 |
160 |
|
125 |
5 |
10/16 |
210 |
56 |
102 |
191 |
147 |
196 |
165 |
299 |
126 |
196 |
|
150 |
6 |
10/16 |
240 |
56 |
116 |
203 |
165 |
225 |
182 |
348.5 |
126 |
196 |
|
200 |
8 |
10/16 |
295 |
60 |
147 |
242 |
182 |
273 |
199 |
397 |
148 |
255 |
|
250 |
10 |
10/16 |
350 |
68 |
182 |
274 |
199 |
304 |
221 |
473 |
148 |
255 |
|
300 |
12 |
10/16 |
400 |
78 |
208 |
312 |
221 |
372 |
249 |
560 |
148 |
255 |
