Pneumatic Hydraulic Di Quick Coupling Valve (DN40-2000)
| Price: |
US $ 10-3000/Set |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1set |
| Pay Type: |
L/C,T/T,D/P,Paypal,Western Union |
DI Quick Coupling
1), Product Information: DI Quick Coupling
SYI Foundry manufactures many different types of ductile iron quick coupling.
SYI Foundry has been supplying coupling for over 10 years and product surface shall be smooth and free from sand holes, blow holes, distortion or any other defects.
2), Material
Body:
Ductile iron grade 500-7/ 450-10 in accordance with ISO 1083 or 70-50-05/65-45-12 with ASTM A536
Gland:
Ductile iron grade 500-7/ 450-10 in accordance with ISO 1083 or 70-50-05/65-45-12 with ASTM A536
Gasket:
Rubber E. P. D. M. /SBR/NR in accordance with EN 681.1
T-BOLTS AND NUTS:
Carbon steel grade 8.8/6.8/4.8 with dacromet coating/galvanization
3), Process
* Automatics machine lines
* Resin Sand
* Molding Boards
* Green Sand with hand molding
4), Inscription Style
* SYI Foundry
* As per customers' requests
* Standard Inscription
5), Packing
* Wood crates
* Wood pallets
* As per customers' requirements
6), Inspection
* Foundry in-house
* Third Party inspection available upon request
More information is available upon receipt of your enquiry.
SYI Industrial Co., Ltd.
You will get our quick reply!
DI Quick Coupling
|
SYI Universal Flanged Adaptors SPECIFICATIONS |
|
Material: |
BODY: Ductile iron grade 500-7/ 450-10 in accordance with ISO 1083 or 70-50-05/65-45-12
with ASTM A536
GLAND: Ductile iron grade 500-7/ 450-10 in accordance with ISO 1083 or 70-50-05/65-45-12
with ASTM A536
GASKET: Rubber E.P.D.M./SBR/NR in accordance with EN 681.1
D-BOLTS AND NUTS: Carbon steel grade 8.8/6.8/4.8 with dacromet coating/galvanization |
|
Flange: |
|
Both PN10 and PN16 drillings in accordance with ISO 7005-2/EN 1092-2 |
|
Working Pressure: |
|
16 Bar or 250 PSI |
|
Fluid Temperature: |
|
0°C-50°C, excluding frost |
|
Allowed Angular Deflection: |
|
3° |
|
Joint Gap: |
|
19mm |
|
Coating: |
Externall coatings:
liquid epoxy resin painting
epoxy applied by FBE
according to customers' requirements |
Internall coatings:
liquid epoxy resin painting
epoxy applied by FBE
according to customers' requirements |
|
Reference Rules: |
|
Designed by SYI and tested in accordance with EN 14525, ANSI/AWWA C219 and EN 545 |
|
Use: |
SYI Universal Flanged Adaptors , designed by experienced engineers in SYI in 2010 and applied the patent,
with wide range tolerance on O.D. (up to 24mm), SYI Universal Couplings are suitable for jointing
plain-ended pipes with same or different materials and same or different outside diameters within the
pipe O.D. ranges.
The circumferentially ribbed, specially profiled gaskets in the high quality material, provide for smooth
installation by minimizing contact friction and restrict to pull out.
The gasket also provide a leak tight seal across the O.D. range per nominal size and still allow for
thermal expansion and contraction of the pipe (up to 5mm per gasket), facilitated through gasket
deformation.
SYI Universal Flanged Adaptors , with the further more reasonable sizes and ranges, can allow the pipes of
main sizes in the most reasonable location, and the gasket can be at the perfect situation after
assembled. |
Note: The accessories for SYI Universal Couplings are usually supplied by
assembled on the body. |
| Prod Model: |
DN40-2000 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Product: |
DI Quick Coupling |
| Advantage: |
Competitive Price, Best Quality&On-time Delivery |
| Material: |
Iron |
| Connection: |
Flange |
