DESIGN FEATURES:
Fire Safe Design and Construction
Built-in ISO 5211 Mounting for Pad Easy Automation
Anti-static Devices for Ball-stem-body
Blow-out Proof Stem
Double Stem Sealing to Comply with TA-LUFT Requirements
APPLICABLE STANDARDS:
Design: GB/T12237, ASME B16.34, API 608
Fire Safe: API 607 4th 1993
Wall Thickness: ASME B16.34 Class 150/300#, JB/T79
End Flange: ASME B 16.5 Class 150/300#
Inspection & Testing: GB/T13927, API 598, API 6D
|
Diameter |
Size(mm) |
|
mm |
inch |
PN |
D |
L |
H1 |
Double acting pneumatic |
Single acting pneumatic |
Electric |
|
H2 |
A1 |
H2 |
A2 |
H2 |
A3 |
|
15 |
1/2 |
16/25 |
14 |
32 |
87 |
146 |
145 |
165 |
195 |
155 |
72 |
|
20 |
3/4 |
16/25 |
19 |
39 |
91 |
146 |
145 |
165 |
195 |
155 |
72 |
|
25 |
1 |
16/25 |
23 |
45 |
105 |
165 |
158 |
187 |
217 |
152.5 |
160 |
|
32 |
1-1/4 |
16/25 |
30 |
55 |
124 |
165 |
158 |
187 |
217 |
152.5 |
160 |
|
40 |
1-1/2 |
16/25 |
36 |
62 |
132 |
187 |
177 |
197 |
258 |
152.5 |
160 |
|
50 |
2 |
16/25 |
45 |
72 |
147 |
197 |
177 |
297 |
258 |
162.5 |
160 |
|
65 |
2-1/2 |
16/25 |
58 |
95 |
170 |
207 |
196 |
225 |
299 |
186 |
196 |
|
80 |
3 |
16/25 |
67 |
120 |
195 |
225 |
225 |
242 |
348.5 |
186 |
196 |
|
100 |
4 |
16/25 |
76 |
145 |
215 |
242 |
273 |
259 |
397 |
208 |
255 |
|
125 |
5 |
16/25 |
100 |
200 |
245.0 |
259 |
304 |
281 |
473 |
208 |
255 |
|
150 |
6 |
16/25 |
125 |
225 |
280 |
281 |
372 |
340 |
601 |
208 |
255 |
|
200 |
8 |
16/25 |
195 |
275 |
335 |
360 |
461 |
463 |
738 |
242 |
310 |
Hangzhou Pass Fluid Equipment Co., Ltd. is a special corporation engaged in research, development and manufacture of fluid equipment, with its main service focusing on water treatment, pipeline connectors (COUPLING) valve and water pump. Relying on its own forces, the company makes ceaseless innovation, actively introduces foreign advanced management methods and marketing idea, constantly taps potential, carries out wide exchange and cooperation. It has established good cooperation relationships with domestic famous institutes and universities and overseas enterprises.
It is sited by the side of the beautiful West Lake, in the center of the Canal Culture Square, and adjacent to the Gland Canal. It owns modern office building, and has built modern development and production base with the great support from Zhejiang University, undertaking engineering services in water treatment, pipeline valve.
As a pioneer in the trade, Pass Fluid Equipment Co., Ltd. (PASS) always persists in the business idea of keeping sincere, professional and innovative, ceaselessly develops new technologies, expands new fields and provides client with optimized solutions.
Pass Fluid Equipment Co., Ltd. (PASS) is a professional fluid engineering company specializing in many industries such as power, petrochemicals, chemicals, electron, metallurgy, medicine and real estate and undertaking overall projects such as feasibility study, design, manufacture, works construction and management, and after-sales services.
