Pog High Pressure Gas 24VDC Stainless Steel Miniature Solenoid Valve

Pog High Pressure Gas 24VDC Stainless Steel Miniature Solenoid Valve
Price: US $ 27.6-29/Piece
Trade Terms: EXW
Min Order: 1/Piece
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Contact Supplier
Polovo Valves (Shanghai) Co., Ltd
Showroom Product Company Profile
POG high pressure gas 24VDC stianless steel miniature solenoid valve

Product information:

1: 2 Way normally closed solenoid valve;
Closed when de-energized, open when energized.
2: Body material: Wrought brass, ss304, ss316
3: Voltage: 220VAC /230VAC/380VAC/50/60Hz 24VDC;
Voltage Tolerance: +10% to -10% applicable voltage;
4: Ambient Temp. 0 ~65centigrades / Fluids Temp 0 ~110Centigeades
5: Flow as the arrow. Mounts in any position;
Best position is solenoid vertical and upright direction.
Serialized products. Small in size. Large flow rate. Widely use.
6: Pilot piston type, high pressure forged valve
7: Quick start fast acting, coil can be fix Germany Nass coil.
8: The highest pressure: 100kg, 1/8'', 1/4'', 3/8'', 1/2'', 3/4'', 1'', please select the size you need, thanks; High pressure solenoid valve medium for water, gas, air, oil, etc.

Structure: Direct acting for small miniature size: 1-2.5mm
Pilot type need 0.5bar pressure the valve open, size: 8-25mm
Connection type: G thread, Seal material: VITON, TEFLON.

Each type size drawing and date information please kindly check below information
Polovo valves (Shanghai) Co., Ltd
TEL: + 86 21 68112100
FAX: + 86 21 39652505
Pipe
Size		 Flow size
(mm)		 CV
value		 Differential  pressure (Kgf/cm2) The maximum flow temperature Power  Product model   Weight
(KG)
The minimum pressure   VA
AC
220V		 W
DC
24V
Air
Gas		 Water/ hot water liquid Light oil ≤20CST Body material
AC DC AC DC AC DC Wrought brass Stainless steel
1/8" 1.0 0.04 0 100 75 100 75 100 75 110 24 18.5 POG1-1 POG1-1B 0.43
1.2 0.05 0 90 70 90 70 90 70 110 24 18.5 POG1-1.2 POG1-1.2B 0.43
1.5 0.08 0 75 50 75 50 75 50 110 24 18.5 POG1-1.5 POG1-1.5B 0.43
2.0 0.14 0 35 30 35 30 35 30 110 24 18.5 POG1-2 POG1-2B 0.43
2.5 0.23 0 20 15 20 15 20 15 110 24 18.5 POG1-2.5 POG1-2.5B 0.43
1/4" 1.0 0.04 0 100 75 100 75 100 75 110 24 18.5 POG2-1 POG2-1 0.42
1.2 0.05 0 90 70 90 70 90 70 110 24 18.5 POG2-1.2 POG2-1.2 0.42
1.5 0.08 0 75 50 75 50 75 50 110 24 18.5 POG2-1.5 POG2-1.5 0.42
2.0 0.14 0 35 30 35 30 35 30 110 24 18.5 POG2-2 POG2-2 0.42
2.5 0.23 0 20 15 20 15 20 15 110 24 18.5 POG2-2.5 POG2-2.5 0.42
8.0 1.0 0.5 90 70 90 70 70 50 80 35* --- POG-8 1.26
3/8" 8.0 1.2 0.5 90 70 90 70 70 50 80 35* POG-8 1.24
15 4.2 1.0 75 55 75 55 55 35 110 33 32 POG-14 POG14B 1.45
1/2" 8.0 1.2 0.5 90 70 90 70 70 50 80 35* --- POG-8 1.21
15 4.2 1.0 75 55 75 55 55 35 110 33 32 POG-15 POG-15B 1.4
3/4" 20 7 1.0 65 50 65 50 50 30 110 33 32 POG-20 POG-20B 1.7
1" 25 11 1.0 55 45 55 45 45 30 110 33 32 POG-25 POG-25B 2.1
Prod Model: POG1-1.2B
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Catalogue: Pog High Pressure Gas 24VDC Stainless Steel Miniat
Body Material: Wrought Brass, Ss304, Ss316
Interface Size: 1/8'' 1/4'' 3/8'' 1/2'' 3/4'' 1''
Flow Size: 1.0 / 1.2 / 1.5 / 2.0 / 2.5 / 8.0 / 15 / 20 / 25
Direct Acting Size: 1/8'' / 1/4''
Pilot Type Size: 3/8'' 1/2'' 3/4'' 1''
The Highest Pressure: 100bar
Applicable Medium: Water, Gas, Air, Oil etc
Brand: Polovo
Working Times: 30, 0000
Type: Direct Acting
Connection Form: Thread
Valve Structure: Direct-Acting Piston Structure
Power Supply: DC Solenoid Valve
Application: Household Usage
Our company is specialized in manufacturing pneumatic/electric actuators and control valves. Our company is located in Pudong New Area of Shanghai.

Our company covers an area of 1, 200 square meters. We have set up a head office, a sales department, a technical department, a purchase department, a production department, a QC department, a supply department, and a finance office in our company.

We have a perfect processing center and quality inspection equipment. Our processing center owns 40 sets of lathes, milling machines, and boring lathe numerical control machines. There are 5 imported vehicle processing centers and many high-quality numerical machines.

At present, we mainly manufacture pneumatic actuators, pneumatic ball/butterfly valves, electric actuators, pneumatic/electric control valves, and other wise products. Our products are widely used in petroleum, chemical industry, electric power, metallurgy paper making, light industry, pharmacy industry and food industry.

Our company absorbs advanced technologies. We use CAD, CAE, CAM, FEA and finite element analysis to design products. Our products have attained ISO9001: 2000 international quality system certification.

We hope that we may get a good reputation for high-quality products, reasonable prices and perfect services of customers' support with the aim of "a long-term cooperation based on equality and mutual benefits".
