Technical Specifications
Design standard: API 600,GB/T 12234
Face to face standard: ASME B16.10,GB/T 12221
Flange ends: ASME B16.5,GB/T 9113
Pressure test:API 598,GB/T 13927
Product Specifications
Material: WCB,LCB,WC6,WC9,C12,C5,CF8,CF8M,CF3,CF3M
Nominal diameter: 1/2"~24"(DN15~1500)
Pressure range: Class150~2500(PN10~420)
Operation: Hand wheel,gear, Electric , Pneumati
Design Feature
Stellited seating surface
Bonnet is self-sealing type, effectively preventing medium leakage and improving safety and reliability.
The DISC wedging phenomenon is not liable to be caused when temperature rises
Yongjia Hongye HIGH & Medium pressure valve Co., Ltd., which is specialized in export-oriented valve manufacturer, is located in Oubei, Wenzhou City, Zhejiang Province, the hometown of pump & valve in China.
Integrating manufacturing, sales and after-sales service together, the main products of Hongye are Ball valves, Gate valves, Globe valves, Check valves, butterfly valves, strainers, etc. Working pressure and temperature range up to DN2000(80"), PN42Mpa (Class2500) and -196 to 650 respectively, employing materials from conventional carbon steel, stainless steel, cast iron, such as graphite cast iron, grey cast iron, WCB, A105, WCC, LCB, LCC, WC6, WC9, C5, CF8, CF8M, CF3, CF3M, Inconel and Monel, etc. Our products are widely used by domestic and foreign users in pipelines of petroleum, chemical industry, metallurgy, electric power, military and engineering supporting industries.
The company has always been pursuit of the spirit of "There is no best, only better". We are going to offer excellent quality, ideal price and best service, sincerely welcome all local and foreign customers to establish long-term stable cooperative relationship with us.
