1, Combination of switch and gauge
2, only one set of pressure connections
3. Compact design
4. Easy to install
Specifications:
The Series SG Combination Differential Pressure Switch Gauge simplifies the installation where both a differential pressure gauge and a switch are required. The Series SG couples the reliable K2000 Differential Pressure Gauge with our SA Series Differential Pressure Switch. With the Series SG, it is no longer necessary to mount a gauge in one location and a switch in another with pressure connections to both. A special bracket integrates both products together with a single set of high and low pressure connections and results in a single product that can be easily panel mounted.
The Series SG comes standard with an Adjustable Signal Flag on the differential pressure gauge and a visual setpoint indicating knob on the switch. The Series SG comes fully assembled and ready to install.
SPECIFICATIONS
Media: Air
Accuracy: (Gauge) +/- 2% full scale (+/- 3% on -0 and +/- 4% on -00) throughout the range at 70° F (21° C)
Repeatability: (Switch) +/- 2%
Dead Band: Approximately 10% of set point
Max Pressure: Switch: 4" w. C. (10000 Pa);
Gauge: 15 PSI (1.034 Bar)
Temperature Limits: 20 to 140° F (-15 to 60° C)
Electrical Rating: 2A @ 250 V2A @ 250 V
Electrical Connection: Screw terminals
Process Connection: 3/16" I. D. Flexible tubing
Enclosure Rating: IP 54
Accessories: 6 ft (1.8m) flexible tubing (2) Static
Pressure fittings Mounting screws
