FEATURES
1. Smaller, Low cost, Easy maintenance
2. Phneumatic control, Hydraulic drive.
3. Hydraulic oil compressed little, so AT30 control characteristic better and accuracy higher.
4. Intrinsic-safe avalible.
5. Easy installation and easy maintenance.
6. Higher cost performance.
7. Controled by solenoid or positioner
------------------------------
Technical Date
1. Power: On/off: 220VAC/24VDC
Modulate: 24VDC(4~20mA)
2. Control accuracy: Same as positioner
3. Weather-proof: IP67
4. Explosion=proof: EExdIIBT4/EExiaIICT4
5. Electric Connection: Same as solenoid or positioner
6. Dead zone: Same as positioner
7. Response time: Same as positioner
8. Hydraulic oil: 10 cst
9. Oil pressure: 16MPa
