Quick-Changeable High Pressure Single-Seated Control Valve K1501

Quick-Changeable High Pressure Single-Seated Control Valve K1501
Price: US $ 1300-15000Per set
Trade Terms: FOB,CFR,CIF
Min Order: 5Sets
Pay Type: L/C,T/T
The K1501 valve is specially used to control cryogenic fluid, and widely applicable to air separated devices as well as the industry of oil, chemical, metallurgy and plant. Multi-spring pneumatic diaphragm actuator or electric motor supplies the power of the valves's action. Pipeless connection makes the valve more compact, more convenient to assemble and disassemble, and have higher reliability.

Characteristics:
1.Unique balance ring structure could increase the differential pressure valve capacity, and better to overcome the phenomenon of cavitation, flashing, etc.
2.Modular design for easy large-scale production and improve the versatility of the spare parts.
3.simple and compact structure, small size,  small loss of the pressure drop, mass flow rate, adjustable wide rangeability.
4.The sleeve could ensure that the body is not destructed by the steam and cavitation and medium erosion, performance is reliable.
5.Simple and easy to change the size of flow capacity and flow characteristics. Variety of valves and valve core material can be chosen optionally for corrosive fluids.
6.The design of inserted style of seat and top-oriented structure ensures quick maintenance and disc replacement.
7.Pipeless connections between the Intelligent positioner and yoke makes the valve more compact, and reduces the leakage point.

Body sizein1123468
mm25405080100150200
Strokemm203060
Press.ratingANSIClassANSI B16.5 ANSI600
PN(Mpa)JB/T79-94 HG20592 PN6.4
Bonnet typeStandard
type
-46 ºC~300 ºC
Fin-
extension
300 ºC~530 ºC
Plug typeParabolic plug
Flow characteristicsEqual percentage, linearity
Leakage classMetallic sealingAccording with ANSI B16.104IV\V
Connection typeFlangedRF\FM\RTJ
Face to face dimensionIEC 534-4-1976 for ANSI\DIN3202-F1 for PN
ActuatorpneumaticMulti-spring  -30ºC~+80ºCReverse action (Signal increase to valve open )
Direct action (Signal increase to valve shut)
ElectricExp.proof  -20ºC~+60ºCReverse action (Signal increase to valve open )
Direct action (Signal increase to valve shut)
Perf.indexlinearity≤±1% (With positioner)
Hysteresis≤±1% (With positioner)
AccessoriesPositioner, Air-set, Hand wheel, Solenoid, Limit switch, Transmitter, Pneumatic accelerator, quick exhaust valve

Prod Model: K1501
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Sealing Form: Gland Packings Globe Valve
Standard: ANSI
Structure: Through Way, Angle Type, 3-Way Type
Material: Wcb, Wc6, Wc9, CF8, CF8m
Jilin city chuanghe liquid control fabrication Co., Ltd., situates in Jilin city and established in 2007, is a leading private company engaged in research, design and manufacturer of control valve, with CNY50million of registered capital, 20000 square meters of covered field and 120 employee. The most important differentiating factor in our company is our experiences and optimum utilization of technology of making the products applying to various services.

The products are widely applied to the industries of petrochemicals,

Pharmaceutical, power plants, food and beverage, paper and fiber.

It is certified by ISO 9001, GB/T24001-2004/ ISO14001: 2400, GB/T28001-2001 and hold Manufacture License of Special Equipment People' S Republic of China (Certificate No.: Ts2710S46-2015). We are the qualified supplier of China National Petroleum Corporation.

We aim for a long lasting customer relationship based on quality. Quality has the top-ranking within our corporate policy.
