R134A Danfoss Thermostatic Expansion Valves (TGEL Series)
Danfoss Thermostatic Expansion Valves (TGEL Series)
Product Description
TGE is an innovatively designed series of thermostatic expansion valves for all fluorinated refrigerants, including R410A. TGE has copper connections upgraded to high-pressure applications for hermetically tight soldering.
Product Features
TGEL, R410A Max. operating temperature, valve body: 110°C / 230°F. Max. working pressure: 46 bar / 667 psig. Max. test pressure: 51 bar / 740 psig. TGE valves are designed for biflow operations.
Regriratant: R22/R404A/R507
Thermostatic expansion valve regulate the flow of refrigerant liquid into The evaporator. The flow is controlled by the valve is thermal bulb which is Attached to the suction line at the outlet of the evaporator. The thermal Bulb senses the evaporator heat and adjusts the valve to admit refrigerant Liquid in accordance with the refrigerating load.
DanfossTGEL13 R410a 067N3157
TGEL R410A
[° C]-40 - 10 ° C
[° F]-40 - 50 ° F
13TR 45KW
[in] 5/8 inX7/8inX1/4in
| Brand: | Danfoss |
| Colour: | - |
| Connection Size: | - |
| Connection Type: | - |
| Length (M): | - |
| Material Type: | - |
| Model Number: | TGEL Series |
| Nominal Running Current (A): | - |
| Operating Temperature: | - |
| Pressure: | - |
| Voltage: | - |
| Warranty: | 1 Year |
| Phase: | - |
| Refrigerant Suitability: | R410A |
| Valve Connections: | - |
| Defrost: | - |
| Evaporator Fans: | - |
| Cable Length (mtr): | - |
| TGEL15 | 54 | 5/8 ×7/8 | 067N315 9 |
| TGEL15 | 54 | 5/8 ×11/8 | 067N316 0 |
| TGEL19 | 68 | 5/8 ×11/8 | 067N316 1 |
| TGEL19 | 68 | 7/8 ×11/8 | 067N316 2 |
| TGEL23 | 79 | 7/8 ×11/8 | 067N316 3 |
| TGEL23 | 79 | 7/8 ×13/8 | 067N316 4 |
| TGEL3.5 | 12 | 3/8 ×5/8 | 067N315 0 |
| TGEL3.5 | 12 | 1/2 ×5/8 | 067N315 1 |
| TGEL4.5 | 16 | 1/2 ×7/8 | 067N315 2 |
| TGEL6.5 | 24 | 1/2 ×5/8 | 067N315 3 |
| TGEL6.5 | 24 | 1/2 ×7/8 | 067N315 4 |
| TGEL6.5 | 24 | 5/8 ×7/8 | 067N315 5 |
| TGEL9 | 32 | 5/8 ×7/8 | 067N315 6 |
| TGEL13 | 45 | 5/8 ×7/8 | 067N315 7 |
| TGEL13 | 45 | 5/8 ×11/8 | 067N315 8 |
| TGEL31 | 110 | 7/8 ×11/8 | 067N316 5 |
| TGEL31 | 110 | 11/8 ×13/8 | 067N316 6 |
| TGEL35 | 125 | 7/8 ×13/8 | 067N316 7 |
| TGEL35 | 125 | 11/8 ×13/8 | 067N316 8 |
| TGEL46 | 161 | 11/8 ×13/8 | 067N316 9 |
