DESCRIPTION
1. Design confirms to: DIN3352, BS5163, SABS664/665
2. Face to Face: EN 558, SABS 664
3. Socket ends: Fitted with NBR/EPDM rubber seal to suit PVC-pipes
4. Normal pressure: 1.0MPa, 1.6MPa, 2.5MPa
5. Test & Inspection: DIN 3230, BS 6755
6. Suitable medium: Water and neutral liquid
7. Working temperature: NBR≤ 80, EPDM≤ 120
8. Operator: Handwheel, nut, extension stem, gear operator
MATERIAL LIST
No. PART MATERIAL
1 BODY GGG40/GGG50
2 WEDGE GGG40/GGG50/NBR/EPDM
3 STEM NUT BRASS/BRONZE/59-1/CZ132/5-5-5
4 STEM 2Cr13/420/304
5 BONNET GGG40/GGG50
6 GLAND BRASS 59-1
7 HANDWHEEL GGG40/GGG50
We are manufacturer and supplier of pipe line products and plumbing fittings, our main products including pipe fittings, malleable iron fittings, grooved ductile iron fittings, cast iron fittings, ductile iron fittings, butt welding fittings, sockets nipples and thread nipples, valves gate valves, swing check valves, butterfly valves, Y strainers, knife gate valvesbrass valves; Seamless and welded pipes, copper tubes, stainless steel tubes. Grooving machine'; UL/FM clevis hangers, stainless steel hubless couplings, rubber expansion joints, flanges, petro tapes and so on.
