| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 10/Piece |
| Pay Type: | T/T,Western Union |
Working medium:Water, hot water <20CST
Medium temperature:0~100
Working pressure:0~8 bar
Work style:Normally closed
Valve body material:PP
Sealing material:EPDM
Coil parameters:AC220V/110V 50/60Hz 7VA;DC 24V/12V, 5W.IP54, available for other voltages
| model | connection |
orifice size (mm) |
CV value | L (mm) | H(mm) | WORKING PRESSURE(BAR) |
| RSC-1 | G1/8'' | 2.5 | 0.2 | 38 | 67 | 0~8 |
| RSC-2 | G1/4'' | 2.5 | 0.2 | 38 | 67 | |
| RSC-2 | quick connection | 2.5 | 0.2 | 40 | 67 | |
| RSC-2L | 2.5 | 0.2 | 54 | 56 | ||
| RSC-8 | 8 | 1.3 | 65 | 61 | 600mm water pressure | |
| RSC-10 | 10 | 2.3 | 69 | 61 | ||
| RSC-12 | 12 | 3 | 59 | 70 |
| Prod Model: | RSC |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Certificate: | Uso CE RoHS FDA |
| Size: | 1/8~1/4 |
| Type: | Direct Acting |
| Connection Form: | Thread |
| Valve Structure: | Direct Action Diaphragm Structure |
| Power Supply: | AC Solenoid Valve |
| Application: | Household Usage |
