Advantages:
Sealing:better acid proof,alkali proof and high temperature performance . Less permanent compression derorm.
Investment forging valve plug: Pressure durability<1.2Mpa,Metallographic stucture better than casting ones.
Appareant design : Keep updated with international fashion-style .
Cost perforemance;Import substituted ,cost saved,reliable opperation.
Material;
Material contact parts:304or316L
Sealing material:
Standard:EPDM , SILICON,FDM,HNBR
Joint style:
Weld,thread,clamp,weld/thread , flange
To assure the connection and substitution with imported facilities , all the connection styles with pipe or equipment are made to DIN1850,IDF/ISO,SMS international standard size.
Pneumatic actuator features:
NO spring open/pneumatic off
NC/OFF signal feed back inductive proder for option
Compact appearance , small volume ,large torgue
Simple and convenient assembly
Technical parameter:
OD Range:DN25~DN200 1"-8"
Anti-pressure air supply :Min:4bar Max:8 bar
Pneumatic actuator torgne :40Nm
Finishing
Cutting:Ra1.5~3.2um
Polish:Ra0.4~0.8um
Requirements for compressed air quality that the executor needs
Compressed air joint :air pipe equiped with air adapter R1/8"
Max grain size :0.01mm
Max oil content :0.08ppm
Dew point :10 or less
Max water content :7.5g/Kg
YUY Fluid Equipment Co., Ltd, located in Wenzhou, is one of the few domestic manufacturers of high precision fluid equipments.
YUY is specialized in Manufacturing
Sanitary Pumps
Sanitary Valves
Sanitary Pipe fittings etc.,
Which can be widely used in food, beer, beverage, dairy products, cosmetic, pharmacy and biology engineering field.
For that our products will be applied in the fluid systems with strict sanitary and sterilizing requirement, so we do have many strict tests for our products, such as the performance curve test of pumps, frequency curve, the smooth and clean test, pressure test and so on.
All the commodities are made in accordance with the standards of ISO, IDF, DIN and 3A. The technology is comparable to the international level in the same field and the quality complies with the requirements of GMP. And the production of YUY is based on advanced manufacture technology and a high sense of responsibility, so that we can provide our customers the products with high quality and high precision.
In addition, our R&D department can explore new products according to out customers' particular requirement. And our production capacity is very great and efficiency, so we can supply the products with best delivery date.
Under the principle of that "the customers are our best inspectors; The market is the most impartial judge of enterprises; Our mission is to provide good quality products with competitive price and satisfactory service for our customers "YUY believe that our honesty, enthusiasm and enterprise will win your support. We are looking forward to starting cooperation, and establish mutual-benefit relationship with our customers, and reach win-win.
Come, and join us!
