Sanitary Stainless Steel Two Pieces Ball Valve

Name: Sanitary Stainless Steel Two Pieces Ball Valve
Brand: Valve Industry
SKU: 637674475
Availability: InStock
Rating: 4.4 (89 reviews)

Price:	US $ 15/Piece
Trade Terms:	FOB,CFR,EXW
Min Order:	10/Piece
Pay Type:	T/T,Western Union

Contact Supplier

Shanghai Kaiquan Machine Valve Co., Ltd.

Showroom Product Company Profile

2pc ball vavles,

BSP Threaded ball valves

Application Fields

Construction, Chemical Industry ,Petroleum ,Metallurgy, water supply

Foodstuff

Specification:

Size:DN8-DN100

Nominal pressure:PN16

Applicable Temp. -20°C~150°C

Design standard:GB/T 12237-2007

Test standard:GB/T 13927-2008

2 PC Ball Valve Economic Type China
2PC Stainless Steel Ball Valve
stainless steel ball vavle economic type

Sanitary stainless steel Ball Valve

Clamped Flanged
Welded threaded
Pneumatic solenoid
DIN,SMS,ISO, 3A, BPE, CMP,IDF,RJT

Sanitary Stainless Steel Ball Valve

1) Specification:DN15-200 & 1/2''-8''
2) Standard:DIN,SMS,ISO, 3A, BPE, CMP,IDF,RJT

3) Material:Stainless steel 304, 316L

4) Gasket: EPDM ,Silicon

5)Connection:welded,clamped,threaded, flanged

6) Applications:Pharmacy, beer, food, petroleum, dairy beverage, cosmetics,etc

7) Certificate: ISO9000:2001

Shanghai Kaiquan Machine Valve Co., Ltd was founded in the 90s of last century, is one of the professional enterprises that produces, sales of the hygiene grade pipe fittings valves, the stainless steel industrial pipeline fittings, all products of hygiene grade can be made according to the different smooth degrees, materials and industrial standards (ISO, DIN, IDF, SMS, 3A), etc., the industrial pipe fittings can be manufactured according to the standards such as GB, HG, HGJ, SHJ and API, ANSI, MSS-SP and BS, NID, JIS, NF, every product technology reach the international advanced level, the products are applied to relevant industrial fields such as beer, dairy products, pharmacy, beverage, food, petroleum, chemical industry, papermaking, natural gas extensively.

Sanitary Stainless Steel Ball Valve

DN	SIZE	Diam B	E	L	W	H
15	1/2	15	12.5	55	105	54
20	3/4	20	14.5	65	110	59
25	1	25	17	75	130	66
32	1-1/4	32	17	85	140	80
40	1-1/2	38	18	95	165	86
50	2	49	18	110	175	95

Prod Model:	ISO, SMS, DIN,
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Standard Or Nonstandard:	ISO, SMS, DIN
Power:	Manual
Media:	Water
Port Size:	1"-4", Dn25-Dn100
Pressure:	Low Pressure
Temperature Of Media:	Low Temperature
Product Material:	Stainless Steel 304/316
Model Number:	ISO, SMS, DIN, 3A
Brand Name:	Kq
Place Of Origin:	China (Mainland)
Connection Form:	Thread
Channel:	Straight Through Type
Structure:	Fixed Ball Valve
Type:	Fixed Ball Valve
Material:	Stainless Steel
Application:	Industrial Usage

Shanghai Kaiquan Machine Valve Co., Ltd., located in the South of Shanghai, is a modern enterprise which integrates scientific research and production. We are one of the few manufacturers which are capable of producing high-precision stainless steel sanitary equipment and pipeline connection parts.

Our products adopt production craft and technology from the EU. Meanwhile, we import foreign advanced numerically controlled machine tools and other process/inspection units. Our company specializes in producing sanitary stainless steel fluid equipment, valves and pipeline connection units. All the products are strictly manufactured according to different standards (such as ISO, DIN, IDF, SMS and 3A). With the efforts of all scientific research personnel, we are keeping on developing new products. Our products are widely used in the fields of food, pharmaceuticals, dairy, beer, beverage and chemical industry. All the technical aspects have reached the international leading levels and are in conformance with GMP requirements. Large quantities of our products are exported to the USA, Europe, the Middle East, Southeast Asia and other countries and regions all over the world.

"Honesty, open-minded and development" is our operation conception. We will appreciate clients' support and valuable suggestions. All those inspire KAIQUAN people to perfectly combine high-quality materials, sophisticated designs, strictly manufacture process and quality assurance systems. The trust of our clients makes us provide them with the best products.

Our mission: Devoted to Human Being's health

Our target: Developing superior technology and pursuing excellence

Our culture: Innovation, unity and practicality.

With full passions, KAIQUAN welcomes your participation and sincerely awaits your visiting!
