1. Standard: JIS
2. Type: Gate valve, globe valves, angle valves, swing check valves
Angle storm balves, air vent, can water filter
3. Body: Cast steel, cast iron
4. Disc: Cast steel, cast iron, bronze
5. Seat: Brass, cast steel
6. Stem: Stainless steel, brss
7. Pressure: 5K, 10K, 16K
8. Size: 2''-12''
9. Packaging: Export poly wooden cases or as per customers' requirements
10. Deliver time: 35 days after order conformed
11. Payment: By T/T or L/C
12. Application: Shipbuild industry etc.
| test pressure(Mpa) |
| seal Mpa | 1.54 to0.4 |
| intensity Mpa | 2.1 |
| maximum working pressure (Mpa) |
| oil and water | 1.0 |
| mon-shock water of 120°C or less | 1.4 |
| parts name | material |
| name | grads | standard No. |
| body | cast iron | HT200 | GB12226 |
| cover |
| disc | cast bronze | ZcuSn5 Pb5Zn5 | GB12225 |
| seat ring |
| rocking |
| Nominal DN | Out-form dimension | Connection dimension of flang |
| L | H | D | D1 | b | n-d0 |
| 50 | 210 | 125 | 155 | 120 | 20 | 4-19 |
| 65 | 240 | 152 | 175 | 140 | 22 | 4-19 |
| 80 | 270 | 154 | 185 | 150 | 22 | 8-19 |
| 100 | 300 | 171 | 210 | 175 | 24 | 8-19 |
| 125 | 350 | 198 | 250 | 210 | 24 | 8-23 |
| 150 | 400 | 224 | 280 | 240 | 26 | 8-23 |
| 200 | 480 | 261 | 330 | 290 | 26 | 12-23 |
We are one of the biggest manufacturers and exporters of Pipeline products in China. We supply butt-welding pipe fittings, stainless steel screwed pipe fittings, forged steel flanges, cast iron valves, cast steel valves, stainless steel valves, balance valves rubber expansion joint, and much more. With many years of effort and support from our valuable customers, these products have obtained a big marker share in the world. At present our products have been export to Asia(Singapore, Tailand, Saudi Arabia, Bahrain, Yemenm, Jordan)Europe(Gemany, Italy, Spain, France, Portudal, Poland)Africa(Egypt, , Camaroon, Morocco)America(USA, Chile, Peru, Panama, Brazil, Paraguary Mexico)
Our business policy is noted for four "F":
Quality First Reputation First.
Customer First Price Fair.
Friends, traders and manufacturers all over the world are welcome to join us establishing and developing business relations on the basis of equality and mutual benefit under the principle of "Provide The World Market With High Quality Goods And Best Service".
Any information, samples and drawing s that you can provide will facilitate us to make the correct supply to meet your special requirement.
