Valve usually manually operated, which is used to release air from a water pipe or fittingS.
Micro Air Release Valve, Automatic Air Release Valve's Specifications, as follow:
Connection dimension of flange:
PN10 PN16 PN25
Be suitable for the tubing of high buildings and fact ories and small pump station. It is used to protect and improve the efficiency of water delivery and save the energy.
Advantages:
It uses the simple lever type micro air exhaust valve. It is an elliptic valve body. All the parts including the floatball, thelever the lever brackdand the valve seat are made of 304 stainless steels. It uses the standard air outlet 1/15", which can be used in the working pressure PN1.6.
Be suitable for the heat air conditioning system.
Advantages:
Be installed at the commanding point or the elbow in order to exclude the unnecessary air in the pipe and improve the service efficiency of the pipe and reduce the consumption of energy.
Materials
Bonnet: Ductile iron
Seat: Stainless steel
Lever bracket: Stainless steel
Lever: Stainless steel
Chock plug: Synthetic rubber
Float ball: ABS
Bolt: Galvanized steel
Inside/outside Fusion Bonded Epoxy.
Class: PN6, PN10 and PN16
Material: Ductile iron
Inner female thread according to BSP (1 or 1 1/4 inches)
Flange drilled: DIN, BS, JIS, ANSI and AWWA
