| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1000/Piece |
| Pay Type: | L/C,T/T,D/P |
|
Product Name |
Sintered part |
|
Raw Materials |
MPIF FC-0205 |
|
Feature |
1. Density from 6.2-6.6 g/cm3 2. Hardness: HRB 60-100 3. Steam treatment: 2H high temp steam holding time, Thickness of Fe3O4: 0.004-0.005mm 4. Full line products for shock absorber, including powder metallurgy piston, rod guide, band for piston, Du bearing for rod guide. 5. PPAP III is submitted accordingly. |
|
Application |
Car shock absorber, Motorcycle shock absorber, Bicycle shock absorber |
|
Processing |
Mixing powder__Forming__Sintering__Sizing__After treatment__Steam treatment__Oil impregnant__Packing__Shipping |
|
Manufacturability |
1. Auto Mechanical Press: 50T, 100T, 140T 2. Hydraulic Press: 100T, 315T, 600T, 800T 3. Six sinter furnaces, including one harden Sinter Furnace 4. Heat treatment: Carbonitriding quenching and high frequency quenching 5. Ultrasonic clearing and auto deburring 6. In-house tooling making: EDM, wire cutting machine 7. Strength in machining: Machine center, CNC milling, CNC lathe, Two end lapper etc. |
|
Test Ability. |
1. Carbon selfur determinator 2. Metallurgic microscope 3. Hydraulic universal material tester 4. Hardness testers 5. Pneumatic measuring instrument 6. Measuring projector 7. Gear testing instrument 8. Electrical profilometer 9. CMM |
|
QMS |
ISO9001:2008, ISO/TS16949:2009, ISO14000:2004, OHSAS18001:1999 |
|
Advantage |
1. Well experienced OEM manufacturer 2. 15 years in the powder metallurgy industry 3. Professional technology service 4. Familiar with automobile industry requirement. |
| Prod Model: | According to Customers Request |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Surface: | Steam Treatment |
| Service: | OEM |
| Type: | Hydraulic |
| Part: | Bumper/Buffer |
| Spring Type: | Coil Spring |
| Spring Material: | Steel |
| Position: | All |
