Features
1. With a bypass valve, in down position, when the hydraulic oil flow can be obtained by proportional control pneumatic pilot valve
2. Dump truck lift valve
Our company produces the hydraulic valves for ten years.
3. The hydraulic valves made in very good conditions.
4. Proportional control valve has the lift, stop, drop of control handle and power take off controlling switch.
5. The valve could arbitrary adjust the pressure in the process of dropping and control the reversing valve of air oil discharge quantity. When it stops or drops, Most importantly, the transportation clearly and definitely.
Valve Specification
Peak pressure: 35MPa
Pneumatic pressure: 0.6-1MPa
Max discharge: 220L/min
"T"point pressure: 1.5MPa
Filtration precision: ≤ 25μ M
Weight: 6.4kg.
|
model |
JHQF-34BQK |
|
hydraulic tube fittings |
G1" |
|
peak pressure |
35MPa |
|
pneumatic pressure |
0.6~1MPa |
|
max discharge |
220L/min |
|
"T" point pressure |
1.5MPa |
|
valve size |
25mm |
|
Filtration precision |
≤25μm |
|
rated pressure |
19~22MPa |
|
viscosity |
12~100mm2/s |
|
temperature |
-25~80 centigrade |
|
weight |
6.4Kg |
Hubei Jiaheng Technology Co., Ltd located at Yunxian economic development. Our company is keen to develop and produce all kinds of hydraulic system products, hydraulic cylinder set, pump truck hydraulic(arm support and pump over), truck mounted crane cylinder, mining hydraulic prop, enlarge frame set and hydraulic system.
Our annual output value above 800 million yuan, anual production capacity of 220000 sets, front telescopic hydraulic cylinders achieve the ability 400units/day, with an annual 120000 units, abdominal lift hydraulic cylinder 40000units, verious types of pump amplitude, telescopic outrigger hydraulic cylinder 10000units, various types of loader, excavator hydraulic cylinders 50000sets.
"Jiaheng" brand hydraulic products has leapt to the leading position in domestic industry three consecutive years. Products reconginzed and praised by more than 100 China several well-known medium and heavy vehicle refitting enterpriese, established a strategic partnership, like XCMG, ZOOMLION, CIMC, SUNHUNK, FOTON, DONGFENG, CAMC, SINOTRUCK, LOXA, Iveco (Shanghai), North Benz. Jiaheng products has spread more than 30 provinces and exported to Russia, Ukraine, Philippines, Thailand, Pakistan, Kazakhstan, Korea and some Middle East countries.
Jiaheng welcome your inquire and visit.
