| Price: | US $ 1.52/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIP |
| Min Order: | 50/Piece |
| Pay Type: | L/C,T/T,D/P |
| Model |
4V 210 -06 |
4V 220 -06 |
4V 230C -06 |
4V 230E -06 |
4V 230P -06 |
4V 210 -08 |
4V 220 -08 |
4V 230C -08 |
4V 230E -08 |
4V 230P -08 |
| Working medium | Air (40 Micro cleaned) | |||||||||
| Motion pattern | Internal Pilot | |||||||||
| Position number | Five-mouth two-position | |||||||||
| Effective section area |
14mm2 Cv=0.78 |
12mm2 Cv=0.67 |
16mm2 Cv=0.89 |
12mm2 Cv=0.67 |
||||||
| Adapter's caliber | Air-in=air-out=exhausting=PT1/8 |
Air-in=air-out=PT1/4 exhausting=PT1/8 |
||||||||
| Lubrication | No requied | |||||||||
| Working pressure | 1.5~8.0kgf/cm2 | |||||||||
| Biggest withstanding pressure | 12kgf/cm2 | |||||||||
| Ambient temp. | -5~60C | |||||||||
| Voltage range | -15%~+10% | |||||||||
| Power consumption |
AC380V 2.5VA, AC220V 2.0VA, AC110V 2.5VA, AC24V 3.5VA, DC24V 3.0W DC12V 2.5W |
|||||||||
| Insulation | Class F | |||||||||
| Protection class | IP 65(DIN40050) | |||||||||
| Electrifying model | Lead or Box type | |||||||||
| Highest action frequency | 5/sec | 3/sec | 5/sec | 3/sec | ||||||
| Response time | 0.05S | |||||||||
| Weight | 220g | 320g | 400g | 400g | 400g | 220g | 320g | 400g | 400g | 400g |
| Prod Model: | 3V 4V |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Specification Code: | Five-Mouth Two/Three-Position Solenoid Valve |
| Type: | Direct Acting |
| Connection Form: | Thread |
| Valve Structure: | Direct-Acting Piston Structure |
| Application: | Water Industrial Usage |
| Power Supply: | AC or DC Solenoid Valve |
