Medium: Air, Gas, Water, Oil, etc,
Temperature: -5 to 80, Max 150
Thread: 1/2" to 1"
Pressure: 0 to 16 Bar
Seal: NBR, VITON
IP65
| 0927000 | 0955105 | 8 | G1/4 | DC12-220V
AC12-380V | 0.07-1.6 | 0.07 | 1.5 | ≥0.33 |
| 0927100 | 0955205 | 12 | G3/8 | 1.7 |
| 0927200 | 0955305 | 12 | G1/2 | 1.7 |
| 0927300 | 0955405 | 20 | G3/4 | 5.1 |
| 0927400 | 0955505 | 25 | G1 | 5.35 |
| 0927500 | 0955605 | 32 | G1 1/4 | 0.1-1.6 | 0.1 | 20 | ≥0.5 |
| 0927600 | 0955705 | 40 | G1 1/2 | 25 |
| 0927700 | 0955805 | 50 | G2 | 43 |
Specification
Model 2W160-10 2W160-15 2W200-20 2W250-25 2W350-35 2W400-40 2W500-50
Working Medium Air, Water, Oil, Gas
Motion Pattern Direct Drive Type
Type Normal Close Type
Aperture of Flow Rate mm 16 20 25 35 40 50
CV Value 4.8 7.6 12 24 29 48
Joint Pipe Bore 3/8" 1/2" 3/4" 1"11/4" 11/2" 2"
Operation Fluid Viscosity 20CSTBelow
Working pressure Air: 0~1.0Mpa\ Water: 0~0.7Mpa\ Oil: 0~0.7Mpa
Max. Pressure Resistance 1.0Mpa
Operating Temperature -5~80 degree
Voltage Range: 10%
Material of Body Brass
Material of Oil Seal NBR or VITON
Model | 2W160-10 | 2W160-15 | 2W200-20 | 2W250-25 | 2W350-35 | 2W400-40 | 2W500-50 |
| Working Medium | Air, Water, Oil, Gas |
| Motion Pattern | Direct Drive Type |
| Type | Normal Close Type |
| Aperture of Flow Rate mm | 16 | 20 | 25 | 35 | 40 | 50 |
| CV Value | 4.8 | 7.6 | 12 | 24 | 29 | 48 |
| Joint Pipe Bore | 3/8″ | 1/2″ | 3/4″ | 1″ | 1 1 /4″ | 1 1 /2″ | 2″ |
| Operation Fluid Viscosity | 20CSTBelow |
| Working -pressure | Air: 0~1.0Mpa. Water: 0~0.1Mpa. Oil: 0~0.1Mpa |
| Max. Pressure Resistance | 1.0Mpa |
| Operating Temperature | -5~80 degree |
| Voltage Range | ±10% |
| Material of Body | Brass |
| Material of Oil Seal | NBR or VITON |
Why choose us?
(1) Quality, we only produce top-level quality products, we promise that all of our product's raw material are first class, and good quality system controls, so our goods' quality is very good.
(2) Price, our policy is that "Win-to-Win". That means in view of our long-standing business relationships, we only take small profit to help you for the marketing.
(3) Delivery, we alway have some products in stock, so we can complete the delivery within the time stipulated before.
(4) No MOQ, I think it is an attractive condition to some of you who have no big demands for each items temporarily.
Ningbo Hi-Tech Smart Pneumatic Co., Ltd. is specialized in manufacturing all kinds of hydro pneumatic components, aluminum parts and plastic parts. Our main products are including pneumatic cylinder, (air cylinder), solenoid valve, air filter, air regulator, air lubricator, pneumatic fitting, hydraulic fitting, tubes, muffler (silencer) etc.
SMART PNEUMATIC take the lead in passing ISO9001 quality system certification and UKAS system certification in this industry and equip with a complete set equipment (CNC machine, data control lathe, and all kinds of testing machines) and checkout system. Under the joint effort of all our members, SMART PNEUMATIC has already established a strong foundation today.
SMART PNEUMATICS' Sprit is to give you the best quality, the competitive price, the quick delivery, the perfect service. Our goal to customers is "Always Smart Solution for your Automatic System. "
SMART PNEUMATIC believes our profession and efficiency will make your international business easier and quicker.
SMART PNEUMATIC hopes to work together with you, developing in parallel!
