Spirax Sacro Steam Control Pilot Operated Pressure Reducing Valve (Dp17)
| Price: |
US $ 130/Piece |
| Trade Terms: |
FOB,CIF,EXW |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Paypal,Western Union |
This Pilot Operated Pressure Reducing Valve product another prominent features: the same body can be installed and exchange the voltage valve in the more than at the same time, realize temperature control, upstream pressure control, remote switch control, etc. Super high sensitivity guide type diaphragm valve main technical parameters and performance indicators. |
GADP17 Pressure Regulator's main technical parameters and indexes of performance.
Nominal pressure | PN25 | Maximun design pressure(PMA) | 25bar g @ 120 | Maximun design temperature(TMA) | 232 @ 21bar g | Minimun design temperature(TMI) | -10 | Maximun upstream pressure for saturated steam service(PMO) | 17barg | Maximun operating temperature(TMO) | 232 @ 21bar g | Minimun operating temperature(TMIO) | 0 | Maximun differential pressure( PMX ) | 17bar | Maximum cold hydraulic test pressure | 38bar g |
|
Material Of Main Component.
Name of component | Material of component | Valve body, valve cover | WCB | Valve seat | 2Cr13 | valve flap | 2Cr13 | Valve rod | 2Cr13 | Membrane | Brass | Adjusting spring | 60Si2Mn |
|
GADP17 Pressure reducing Valve 's connecting dimension
DN | L | H1 | H | D | 15 | 147 | 221 | 133 | 185 | 20 | 154 | 224 | 136 | 185 | 25 | 160 | 235 | 145 | 207 | 32 | 180 | 236 | 156 | 207 | 40 | 200 | 238 | 176 | 255 | 50 | 230 | 246 | 183 | 255 | 65 | 250 | 295 | 200 | 320 | 80 | 310 | 323 | 230 | 350 | 100 | 350 | 340 | 263 | 380 | 125 | 400 | 359 | 306 | 455 | 150 | 450 | 375 | 330 | 500 |
|
| Prod Model: |
GADP17 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model No: |
Gadp17 |
| Size: |
1/2"-6" |
| Category: |
Pressure Reducing Valve |
| Connecting Type: |
Flange |
| Material: |
C.S |
| Medium: |
Steam., etc |
| Working Temperature: |
Below 285 Deg C |
| Usage: |
Pressure Reducing |
| Application: |
Steam System, Air Compressor System., etc |
