| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,D/P,Paypal,Money Gram |
Application
This valve is used for throttling or shutting off the flow of corrosive or non-corrosive gased, liquids and semi-liquid. It can be installed in any selected position in pipelines in the industries of petroleum processing, chemicals, food, medicine, textile, paper making, hydroelectricity engineering, building, water supply and sewage, metallurgy,
energy engineering as well as light industry.
Feature
1.PTFE,FEP,PFA,PVDF,PE,PO or PP Body & Disc Liner
The nonstick and nonporosity properties of the liner ensure high performance of the valve under highly corrosive chemicals in conjunction with high pressure and temperature.
2.Locked in Disc Liner
The liner of this Butterfly valve is securely locked in to cast hole of disc,which helps to prevent liner to collapse in vacuume condition and blow out in high pressure conditions regardless of high temperature.
3.Tight Shut Off
A silicon backing strip is provided inside deep machined body groove for the liner, to resist against the disc edge which creates tight shut-off.
| Prod Model: | D371F4-10/16 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Standard Or Nonstandard: | Standard |
| Brand Name: | Worlds |
| Pressure: | Low Pressure |
| Temperature Of Media: | -40 to +200c |
| Material: | Ductile Cast Iron |
| Seal: | PTFE |
| Power: | Manual |
| Media: | Strong Acid and Alkali and So on |
| Size: | Dn40-400 |
| Place Of Origin: | Tianjin China (Mainland) |
| Work Pressure: | Low Pressure (',Pn<1.6mpa) |
| Material Of Seal Surface: | Soft Sealed |
| Connection Form: | Wafer |
| Structure: | Centre Sealing |
| Seal Form: | Auto Sealed |
| Working Temperature: | Medium Temperature (',120??C |
| Application: | Chemical Engineering |
