Glycol Jacket Beer Fermenter 10000L fermenters (CE approved)
Structure characteristics:
1. Adopt structure of internal tank, jacket and external package, with heat preservation materials inside.
2. Materials are all sanitary stainless steel.
3. Humanized structure design and easy to operate.
4. Transition area of interior wall on tank adopts arc for transition to ensureno dead angle of sanitation.
5. Top head adopts rotary opening type.
FVP Vertical Mixing Hot and Cold Cylinder Series
Structural features:
1. Equipment mainly consists of cylinder, honeycomb jacket and the outer wrapper of three parts, outer wrapper and filled with insulation media folder suites, top with a stirrer.
2. Materials are high quality stainless steel.
Standard configuration:
1. Soon open manhole
2. Digital Thermometer
3. T type cleaning head
4. Rod outlet valve
5. Adjustable cone feet
6. Stirrer.
CE LICENCE
| model | nominal volume(L) | external diameter(D) | overall height(H) | import and export path | motor power(kw) | stirring rate(rotate/minute) |
FVP-600 | 600 | 1000 | 2300 | 38 | 0.75 | Optional speed 14, 18, 24, 28, 35, 47, 56, 70, 94. |
| FVP-1 | 1000 | 1150 | 2530 | 38 | 1.1 |
| FVP-1.5 | 1500 | 1280 | 2700 | 38 | 1.1 |
| FVP-2 | 2000 | 1440 | 2910 | 51 | 1.1 |
| FVP-2.5 | 2500 | 1520 | 3100 | 51 | 1.5 |
| FVP-3 | 3000 | 1640 | 3200 | 51 | 1.5 |
| FVP-3.5 | 3500 | 1700 | 3300 | 51 | 1.5 |
| FVP-4 | 4000 | 1750 | 3500 | 51 | 1.5 |
| FVP-5 | 5000 | 1880 | 3400 | 51 | 1.5 |
| FVP-8 | 8000 | 220 | 4050 | 51 | 2.2 |
| FVP-10 | 10000 | 2400 | 4200 | 65 | 2.2 |
| FVP-15 | 15000 | 2750 | 4600 | 65 | 2.2
|
Zhejiang Mingchen Machinery Science and Technology Co., Ltd., integrating scientific research, design, development, production, installation, after-sale service and consultation, is a high-tech industrial economic entity specializing in producing machinery, equipment such as evaporator, stainless steel tank, fermentor, alcohol(ethanol) production line, Ossein production line, tomato production line, juice production line etc. Its diversified and high quality products have met various demands in the fields of pharmacy, biology, chemical industry, food, dairy, beverage etc.
With the rapid progress of science and technology and the booming development in the information age, by adhering to the traditional operation concept and relying on rich experience in technology, we specialize in producing various tank products for traditional Chinese medicine extracting and concentrating, preparations and fine chemicals, packing machinery, small and medium-sized production lines and other series of products. All procedures including function design, energy data, material selection, welding technology, in-process quality control and appearance beautification are carefully planned and strictly controlled. The products are comparable to those in Europe, America, Japan and other countries and areas. The product quality conforms to the sanitation inspection standards for auxiliary equipment used in food, dairy, beverage and other industries.
Mingchen Machinery introduces specialized technologies from Japan to improve product quality and technical level. With new manufacturing technology, unique flat plate type forming hydraulic end plate, advanced welding, weld pass stress elimination and other cutting-edge production technologies, we are engaged in the R&D and promotion of product functions and service life. The products are in accordance with various quality requirements and inspection standards, receiving deep favor from customers.
