Product Details:
A floating ball valve is a valve with seats supported ball, which is pushed by upstream pressure towards the downstream seat to ensure sealing. This series of valves are usually used in service of low pressure (150~300LB) and wide temperature range (-190~ 500 C). They are characterized by simple design, easy maintenance, low cost and quick delivery. This product line is used primarily in the Oil & Gas, Building and construction Industries, Chemical and Petrochemical services, among others.
Applicable Standard
Design Standard: API 6D, ASME B16.34, API 608, BS 5351, DIN 3357, EN 12516
Face to Face: API 6D, ASME B16.10, EN 558-1
End Connection: ASME B16.5, ASME B16.25, EN 1092-1
Inspection and Test: API 6D, API 598, DIN 3230, EN 12266
Design Features
Full port or reduced port
Floating ball design
Blowout-proof stem
Fire safe design to API 607/ API 6FA
Anti-static devices
Cavity pressure self-relief
Optional locking device
Size: |
1/2" ~ 10" (DN15 ~ DN250) |
Rating: |
ANSI 150lb, 300lb, 600lb (PN10-PN100) |
Body Materials: |
Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel |
Trim: |
A105+ENP, F6a, F304, F316 |
Operation: |
Lever, Gear, Electric, Pneumatic |
|
please contact with us for other sizes, pressures & materials. |
