1. Stainless steel Knife Gate Valve PN10 Pressure rating and size:
* PN10&Class150&10K
* DN50 to DN1200
* 2"~48"
* 50A~1200A
2. Stainless steel Knife Gate Valve PN10 Material:
* Ductile iron: GGG40
* Stainless steel: CF8,CF8M etc.
3. Stainless steel Knife Gate Valve PN10 Operator:
* Manual,Bevel Gear,Pneumatic,Hydraulic,Electric,Chain Wheel etc.
4.Stainless steel Knife Gate Valve PN10 Features:
* Standards: EN1092&MSS SP-81
* End Style: Full lug, Sami-lug, Wafer type
* Certificate: CE,TS,ISO etc.
5. Stainless steel Knife Gate Valve PN10 General Applications:
* Mining
* Power plant
* Pulp and paper
* Alumina
* Chemical
* Cement
6. Stainless steel Knife Gate Valve PN10 The main material to choose from :
1. Product name | Stainless steel Knife Gate Valve PN10 |
2. Brand name | GL valve |
3. Pressure | PN10&Class150&10K |
4. Size | DN50-DN1200&2"-48"&50A-1200A |
5. Body material | DI(GGG40)&SS(304,316)(solid solution treatment) |
6. Gate material | SS304&SS316(solid solution treatment) |
7.Seat material | EPDM&Metal&Viton&NBR |
8.Packing material | PTFE& Silicone |
9.Support plate | A 36+epoxy plate |
10.Operation | Handwheel, bevel gear, DA pneumatic, electric,etc. |
11.Packing | Plywood case |
12.Payment | T/T, L/C, West union 30% before production, balance before shipment. |
13.Quality | Every process is inspected by our QC team |
14.Sample | Ready samples are available for inspection reference |
Established in 1992 and re-established in 2004, Zhejiang Guanli Valve Co., Ltd. Covers an area of 7, 500 square meters located at Dongou Industrial Zone in Wenzhou. Our company is located in Wenzhou, only 500 kilometers from Shanghai Pudong Airport.
We are a professional manufacturer of industry valves according to API, DIN, JIS standards. Our products include knife gate valves, ball valves, gate valves, globe valves, check valves and butterfly valves. Our valves are made with materials of WCB, WC6, WC9, LCB, 304, 316, 304L, 316L and F51. They are widely used in many fields, such as petroleum, chemical, natural gas, power, feed water, steel and metallurgy.
If you are interested in any of our products, please feel free to contact us for more information.
