Stainless Steel Pneumatic Sanitary Butterfly Valves Kt

Stainless Steel Pneumatic Sanitary Butterfly Valves Kt
Price: US $ 68-70/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,D/P,Paypal,Western Union

Stainless Steel Pneumatic Sanitary Butterfly Valve

Features

Nominal Diameter: DN40-600
Pressure Range: 0-1.0 Mpa
Medium Temp: -20--+80
Body Material: Gray Cast Iron, Ductile Cast Iron, Cast Steel, Stainless Steel
Disc: Ductile Cast Iron, Cast Iron, Stainless Steel, Nickel Alloy
Sealing: NBR, EPDM, FPM, PTFE
Actuator Body: Aluminium alloy
Feature: Double Bubble & Zero Leakage, Double acting, Single acting, Stem Without Pin
Medium: Drinking Water, Sewage, High Purity Water, Seawater, Air
Control Pressure: 3-8bar

Specifications

Pneumatic Sanitary Butterfly Valve (Clamp)

1). Nominal Diameter: 1"-4"
2). Pressure Range: 0-10bar
3). Working Temp.: -20°C-+160°C
4). Valve Body Material: Stainless Steel
5). Sealing MaterialNBR, EPDM, FPM
6). Applicable Medium: Tap water, high pure water, sea water, air
7). Actuator Cover: Aluminum alloy
8). Operating Pressure: 3-8bar
9). Type: Double-acting, single-acting

Sanitary Pneumatic Butterfly Valve (Vertical)


1). Nominal Diameter: DN25-100

2). Pressure Range: 0-16bar

3). Working Temp.: -20--+135

4). Sealing Class: ANSI B 16-104, Class VI

5). Actuator: Stainless Steel

6). Valve Body: SS304, SS316

7). Sealing Material: NBR, EPDM, FPM

8). Disc: Stainless steel

9). Feature: Double bubble and zero leakage, double (single) stem without pin

10). Applicable Medium: Drinking water, sewage, high-purity water, sea water, air, etc.

11). Operating Pressure: 3-8bar

Products

Packing


Contact

Thanks for your visiting.

If you have any questions about our products or company, please do not hesitate to contact Olivia hu






BrandKT;OEM
Mediawater,oil,gas,nitric acid,acetic acid
CertificationCE/API/DNV/FDA/ISO9001-2008
PackingPlastic bag,carton/ply-wood case,/according to customer
PaymentL/C,T/T,D/P,WESTERN UNION,PAYPAL
PortNINGBO,SHANGHAI,etc
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Body Material: Gray Cast Iron, Ductile Cast Iron, Cast Steel, Sta
Actuator Body: Aluminium Alloy
Nominal Diameter: Dn40-600
Medium Temp: -20--+80
Disc: Ductile Cast Iron, Cast Iron, Stainless Steel, Nic
Sealing: NBR, EPDM, FPM, PTFE
Medium: Drinking Water, Sewage, High Purity Water, Seawate
Control Pressure: 3-8bar
Kangtuo International Trading Co., Ltd is not only a trading company but a combination of four factories whose products are complementary to each other. Konte deals with Pneumatic Actuator, Electric Actuator (Rotary and Multi-Turn), Ball Valve (Industrial and Sanitary), Butterfly Valve (Industrial and Sanitary), Pneumatic Angle Piston Valve, Diaphragm Valve, Gate Valve, Globe Valve, Check Valve, etc.

Konte makes full use of resources from the four factories, namely, Kangsaite, Homin, Yuanyu and Lianggong and has their technical, quality-control and price support. Established in 1978, Lianggong Valve Co., Ltd. Covers an area of 15000 square meters and produces pressure seat gate valve, globe valve, ball valve, control valves, butterfly valves, check valves, etc. Kangsaite Valve Co., Ltd. Specializes in pneumatic actuator, electric actuator, angle piston valve, diaphragm valve, etc. Yuanyu Machinery Co., Ltd. is professional manufacturer of high-precision sanitary valves & fittings and fluid equipment. Products are widely applied in dairy, beer, food, pharmaceutical, beverage, cosmetics and chemical industry areas. Homin Valve Co., Ltd. Covers an area of 16650 square meters and produces specially metal seated ball valves, floating ball valves, trunnion mounted ball valves and eccentric segmental ball valves which are widely applied to most severe and harsh conditions, such as high-temperature (up to 816º C), high-pressure (up to 15000psi), low-temperature(down to -196º º C), abrasive particulates (catalyst in mine and petro-chemical industry, PTO process, coal dusts and ashes).

With advanced management system and complete quality assurance system, we have got certificates such as CE, ISO, TS, FDA, API, DNV, etc.

We aim at providing one-stop service and offering professional guidance for clients all over the world. With the 4 factories as backup, we believe we will be your good choice for importing, selecting and assembling suitable valves for project, equipment, tender, etc.
