Stainless Steel Pneumatic Sanitary Valves

Stainless Steel Pneumatic Sanitary Valves
Price: US $ 70/Piece
Trade Terms: FOB,CFR,EXW
Min Order: 1/Piece
Pay Type: L/C,T/T,D/P,Western Union,Paypal

Stainless Steel Pneumatic Sanitary Butterfly Valve

Features

1. Tri-clamped Ball Valve
2. Electro and Mechanical Polishing
3. Sealing Material: PTFE, NBR, EPDM, FPM
4. Manufacture Standard: GB, DIN, ISO, SMS
5. Zero Leakage

Specifications

Pneumatic Sanitary Ball Valve (Clamp)

1). Nominal Diameter: DN15-100
2). Pressure Range: 0-16bar
3). Medium Temp.: -10°C~+180°C
4). Ambient Temp.: -10°C~+60°C
5). Valve Body Material: Stainless Steel
6). Sealing Material: PTFE
7).
Actuator Cover: Aluminum Alloy
7). Operating Pressure: 3-8bar
8). Type: Double-acting, single-acting

Pneumatic Sanitary Butterfly Valve (Clamp)

1). Nominal Diameter: 1"-4"
2). Pressure Range: 0-10bar
3). Working Temp.: -20°C-+160°C
4). Valve Body Material: Stainless Steel
5). Sealing MaterialNBR, EPDM, FPM
6). Applicable Medium: Tap water, high pure water, sea water, air
7). Actuator Cover: Aluminum alloy
8). Operating Pressure: 3-8bar
9). Type: Double-acting, single-acting



Sanitary Pneumatic Butterfly Valve (Vertical)


1). Nominal Diameter: DN25-100

2). Pressure Range: 0-16bar

3). Working Temp.: -20°C--+135°C

4). Sealing Class: ANSI B 16-104, Class VI

5). Actuator: Stainless Steel

6). Valve Body: SS304, SS316

7). Sealing Material: NBR, EPDM, FPM

8). Disc: Stainless steel

9). Feature: Double bubble and zero leakage, double (single) stem without pin

10). Applicable Medium: Drinking water, sewage, high-purity water, sea water, air, etc.

11). Operating Pressure: 3-8bar


Manual Diaphragm Valve


1). Nominal Diameter: DN15-50

2). Pressure Range: 0-16bar

3). Medium Temp.: -10°C-150°C

4). Ambient Temp.: -10°C-60°C

5). Valve Body Material: Stainless Steel

6). Sealing Material: NBR, EPDM, FPM

7). Connection: Welding

Pneumatic Diaphragm Valve (Clamp)


1). Nominal Diameter: DN15-50

2). Pressure Range: 0-16bar

3). Medium Temp.: -10°C-+180°C

4). Ambient Temp.: -10°C-+60°C

5). Valve Body Material: Stainless Steel

6). Sealing Material: NBR, EPDM, FPM

7). Actuator Cover: PA

8). Operating Pressure: 3-8bar

8). Type: Single-acting, double-acting


Pneumatic 3-Way Diaphragm Valve


1). Inside and outside of valve body can be sterilized under high temperature

2). Driving Way: Pneumatic, normally closed (1), normally open (2), double direction (3)

4) .Max. Working Pressure: 10bar (Diaphragm is EPR or FPM), 6bar (Diaphragm is PTFE for one-side use)

5). Operating Pressure: 4-6bar (1), 3-4bar (2 or 3)

6). Diaphragm Material: EPDM, FPM, PTFE

7). Valve Body Material: SS316

8). Connection: Welding, Clamp

9). Manufacture Standard: GB, DIN, ISO, SMS


Pneumatic Diaphragm Valve (Stainless Steel Head/Plastic Head)


1). Inside and outside of body can be sterilized at high temperature

2). Driving Way: Pneumatic

3). Max. Working Pressure: 10bar (Diaphragm is EPR or FPM)

4). Max. Working Temp.: 150°C

5). Diaphragm Material: EPR, FPM

6). Valve Body Material: Stainless Steel, 316L

7). Manufacture Standard: GB, DIN, ISO, SMS



Producs Show
Packing Show

Contact

Thanks for your visiting.

If you have any questions about our products or company, please do not hesitate to contact olivia hu





Brand: KT/OEM
Applicable Media: Water, Oil, Gas, Nitric Acid, Acetic Acid
Certification: CE/API/DNV/FDA/ISO9001-2008
Sample Testing: One Sample for free( Under $10),Freight Collect
Packing: Plastic Bag, Carton & Plywood Case/According to customers' requirement.
Payment:  T/T, L/C, D/P, Western Union, Paypal
Port:  NINGBO/SHANGHAI, Customers' Request
Delivery Time: Within 35days after receiving T/T deposit Payment
Term of Delivery: FOB/CNF/CIF, Customers' Request
Prod Model: KT
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size: 3/8"-4"
Place Of Origin: Zhejiang
Diaphragm Material: EPDM, FPM, PTFE
Ball Assembly: Side Entry
Driving Way: Pneumatic, Normally Closed, Normally Open
Valve Body Material: Ss304, Ss316
Actuator Body Material: Aluminium Alloy
IP Class: IP68
Actuator Rotary Range: 90°
Manufacture Standard: GB, DIN, ISO, SMS
Channel: Straight Through Type
Structure: Floating Ball Valve
Type: Floating Ball Valve
Material: Stainless Steel
Application: Household Usage
Connection Form: Clamped
Kangtuo International Trading Co., Ltd is not only a trading company but a combination of four factories whose products are complementary to each other. Konte deals with Pneumatic Actuator, Electric Actuator (Rotary and Multi-Turn), Ball Valve (Industrial and Sanitary), Butterfly Valve (Industrial and Sanitary), Pneumatic Angle Piston Valve, Diaphragm Valve, Gate Valve, Globe Valve, Check Valve, etc.

Konte makes full use of resources from the four factories, namely, Kangsaite, Homin, Yuanyu and Lianggong and has their technical, quality-control and price support. Established in 1978, Lianggong Valve Co., Ltd. Covers an area of 15000 square meters and produces pressure seat gate valve, globe valve, ball valve, control valves, butterfly valves, check valves, etc. Kangsaite Valve Co., Ltd. Specializes in pneumatic actuator, electric actuator, angle piston valve, diaphragm valve, etc. Yuanyu Machinery Co., Ltd. is professional manufacturer of high-precision sanitary valves & fittings and fluid equipment. Products are widely applied in dairy, beer, food, pharmaceutical, beverage, cosmetics and chemical industry areas. Homin Valve Co., Ltd. Covers an area of 16650 square meters and produces specially metal seated ball valves, floating ball valves, trunnion mounted ball valves and eccentric segmental ball valves which are widely applied to most severe and harsh conditions, such as high-temperature (up to 816º C), high-pressure (up to 15000psi), low-temperature(down to -196º º C), abrasive particulates (catalyst in mine and petro-chemical industry, PTO process, coal dusts and ashes).

With advanced management system and complete quality assurance system, we have got certificates such as CE, ISO, TS, FDA, API, DNV, etc.

We aim at providing one-stop service and offering professional guidance for clients all over the world. With the 4 factories as backup, we believe we will be your good choice for importing, selecting and assembling suitable valves for project, equipment, tender, etc.
