Stainless Steel Signal Gate Valve for Oil Gas Water Steam

Stainless Steel Signal Gate Valve for Oil Gas Water Steam:

1. Body material: CF8, CF8M
2. Pressure: Class 150/300/600/900/1500
3. Size: 2" - 36"
4. Operatation: handwheel, bevel gear
5. Standard: API 6D, API 600
6. Flange dimension: ANSI B16.5
7. Text: API 598, API 6D

	Class 150
size(in)	2"	2-1/2"	3"	4"	6"	8"	10"	12"	14"	16"	18"	20"	24"
L,RF(mm)	178	190	203	229	267	292	330	356	381	406	432	457	508
L1-BW(mm)	216	241	283	305	403	419	457	502	572	610	660	711	813
L2-RTJ(mm)	190	203	216	241	279	305	343	368	394	419	445	470	521



	Class 300
size(in)	2"	2-1/2"	3"	4"	6"	8"	10"	12"	14"	16"	18"	20"	24"
L,RF(mm)	216	241	283	305	403	419	457	502	762	838	914	991	1143
L1-BW(mm)	216	241	283	305	403	419	457	502	762	838	914	991	1143
L2-RTJ(mm)	232	257	298	321	419	435	473	518	778	854	930	1010	1165




	Class 600
size(in)	2"	2-1/2"	3"	4"	6"	8"	10"	12"	14"	16"	18"	20"	24"
L,RF(mm)	292	330	356	432	559	660	787	838	889	991	1092	1194	1397
L1-BW(mm)	292	330	356	432	559	660	787	838	889	991	1092	1194	1397
L2-RTJ(mm)	295	333	359	435	562	664	791	841	892	994	1095	1200	1407



	Class 900
size(in)	2"	2-1/2"	3"	4"	6"	8"	10"	12"	14"	16"	18"	20"	24"
L,RF(mm)	368	419	381	457	610	737	838	965	1029	1130	1219	1321	1549
L1-BW(mm)	368	419	381	457	610	737	838	965	1029	1130	1219	1321	1549
L2-RTJ(mm)	371	422	384	460	613	740	841	968	1038	1140	1232	1334	1568



	Class 1500
size(in)	2"	2-1/2"	3"	4"	6"	8"	10"	12"	14"	16"	18"	20"	24"
L,RF(mm)	368	419	470	546	705	832	991	1130	1257	1384	1537	1664	1943
L1-BW(mm)	368	419	470	546	705	832	991	1130	1257	1384	1537	1664	1943
L2-RTJ(mm)	371	422	473	549	711	841	1000	1146	1276	1407	1559	1686	1972

Design standard: API 600,GB/T 12234.
Small flow resistance for fluid.
Only a small force is required for opening/closing.
No limitation on the flowing direction of the medium .
During opening and closing process, the friction between the disc wedge and the seat is small, so the sealing is reliable ensuring tightness and long service life.
The valve is designed in a back-seat structure.
The valve stem sealing is realized by the collaboration of flexible and woven graphite. ensuring a more reliable tightness.
Optional pressure seal bonnet type.
Optional solid-wedge type.
Optional non-rising stem structures.
Optional jacket structure.


Our Advantages:
1.We Are Factory: FYV has 3 production bases and 1 foundry which located in Wenzhou, Shanghai and Lishui city of China. The Factory Size in Square Meters : 110,000. FYV has over 600 staff members, more than 60 technical engineers, a digital process center and more than 350 sets of various middle and large equipments. The annual sales revenue reaches above $80 million US Dollars.
2. Regional Sales: We provide specialized sales service refers to different kind of region all over the world. Each sales team member is good at the local language and well experienced to the responsible market. For example: Russian, German, Spanish, Japanese, etc.
3. Low MOQ: Our factory owns the casting company by itself. We are always ready for providing the sample and producing some small orders, in order to meet the business well.
4. OEM Accepted: We can make the products with the client's demand standard or the custom requirement.
5. Complete Service: We are always ready to hear from you, be responding to your enquiry immediately. Our trade manager is always online for you.
6. Good Quality: We have strict quality control system and amounts of testing equipments for different kind of valve, such as size, pressure, working environment etc. We are winning the market reputation with the time goes by.
7. Quick Delivery: We have the large stock for some hot products.
8. Competitive Prices: We are the manufacturing company which not only has our own manufacturing workshop, but the casting company as well. We provide the straight factory price and service to our customer.
