Stainless Steel Threaded Ball Valve with CE Certificate

Stainless Steel Threaded Ball Valve with CE Certificate
Price: US $ 2/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 10/Piece
Pay Type: L/C,T/T,Money Gram,Western Union
Stainless Steel Threaded CE Ball Valve

Brief description:
1) Size: 1/4~4"
2) Working pressure: 1.6-6.4mPa
3) Temperature range: -20°C ~ 232°C ~ 350°C
4) Suitable medium: water, oil, air, some corrosive liquid
5) Thread type: ZG.G, NPT, BSPT, BSP, DIN259/2999
6) We can also manufacture similar products according to your special requirements







The Above technical data are just for your reference. Any questions please contact us.
Design can be revised according to customer requirement.

NO Part Name Material
1 Body WCB CF8M
2 Ball SS201 SS316
3 Cap WCB CF8M
4 Seat PTFE RPTFE
5 Thrust washer PTFE PTFE
6 Joint Gasket PTFE
7 Packing PTFE
8 Spring washer PTFE
9 Nut A2-70
10 Bolt SS201/SS304
11 Gland SS304
12 Stem SS304/SS316
13 Spring washer SS201
14 Nut A2-70
15 Handle SS201
16 Handle cover PVC

Prod Model: Yuzheng valve-001
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Handle Operation: Lever Handle/Wing Handle
Certificate: CE,ISO
Connection Form: Thread
Channel: Straight Through Type
Structure: Floating Ball Valve
Type: Floating Ball Valve
Application: Household Usage
Material: Carbon Steel
WENZHOU YUZHENG VALVE Co., Ltd has been a manufacturer of Stainless Steel Ball Valves and Pipe Fittings since 1998. With the concept of "Customer First", we have achieved stable and fast development, we will keep on innovation and expand our business all over the world. It is about 5 minutes away from Yongqiang Airport, and half an hour from Wenzhou Train Station. Ningbo Port and Shanghai Port are very close to our factory.

The articles we produce including Stainless Ball Valve, Check Valve, Gate Valve, Strainer, Pipe Fittings and so on. All of them are ISO9001, CE approved. Yuzheng company also been inspected and approved by SGSThe standard of thread are, BSPP, BSPT, NPT, therefore our products can match the requirement of customers from different district. Products' standard including API6D, ASTM, MSS, ANSI, JIS, DIN, ISO, GB, etc. They are widely exported to Southeast of Asia, Middle East, Europe, South America and other areas.

Our strict production and professional sales team will be your guarantee during the cooperation, please don't hesitate to join us if you are specialized in the products.
