Applications
It is widely used in beverage, breweng, oil refinery, cosmetic, chemical industries.
Design and Features
Free of maintenances
Compact and portable
Small operating torque
Gasket complies with PTFE FDA 177.2600
Hand lever can be installed on the side of the valve body, no matter of the flow direction.
Connection ends: Thread, clamp, weld, flange, DIN, SMS, RJT, FIL.
It can be installed with pneumatic and electric actuators.
The part contacted with media is AISI 304/316L
Other parts AISI 304
Certifictions: PED, 97/23/EC
Options
Type of valves: One way ball valve, three-piece ball valve, Three-way ball valve
Ball: T port, L port, direct way
With cleaning and drainage port
Material: AISI 304, 316L
| Product Name: | SS Manual Thread 2 Way Ball Valve FDA CE |
| Valve Body Material: | SS304 or SS316L |
| Seal Material: | PTFE |
| Max. Working Pressure: | 10Bar |
| Max. Working Temperature: | 120 degree C |
| Availably size: | DN10-DN100 or 1/2" - 4" |
| Availably connection: | Thread,Weld,Clamp, Flange |
| Availably standard: | DIN,SMS,RJT, |
| Operated: | Manual,Pneumatic,Electric |
| Certificate: | FDA,CE |
